The below instructions are intended for fitters and users of loft ladders
FAKRO Loft Ladders
User Manual
1
Names of individual components
BOX
SPRING CATCH
HINGE
SIDE BRACKET
CHAIN
(LEFT OR RIGHT)
OPENING
SPRING
METAL HANDRAIL
HATCH
LADDER
CONTROL ROD
CLOSING
HATCH
LADDER
LOCK PLATE
LOCK
STILE ENDS
HATCH
THANK YOU FOR PURCHASING FAKRO LOFT LADDER
We wish you full satisfaction while using our ladders.
Please kindly read this manual before using the ladder, then keep it for future reference and observe it.
Advertisement
Table of Contents
Related Manuals for fakro LW456
Summary of Contents for fakro LW456
- Page 1 LOCK PLATE LOCK STILE ENDS HATCH THANK YOU FOR PURCHASING FAKRO LOFT LADDER We wish you full satisfaction while using our ladders. Please kindly read this manual before using the ladder, then keep it for future reference and observe it.
- Page 2 Do not unscrew the hatch or hardware elements attached to it. exceeds the maximum permissible height specified on the production label. info: www.fakro.com The range of room heights within which it is possible to install loft ladders is, respectively HYGRO...
- Page 3 Safety rules when using the ladder Before using the ladder, check if the length of the ladder is properly matched to the height of the room. The segments of the ladder after unfolding should form a straight line but can not come apart at the hinged connections.
- Page 4 Safety rules when using the ladder The total load of the ladder must not exceed 160kg (person plus objects carried). Any extra Do not use damaged loft ladder (broken tread, damaged hatch or hardware). load may cause damage to the ladder and, consequently, lead to a serious injury. While ascending or descending the ladder, the user should always face the ladder and hold While ascending or descending the ladder, do not hold onto the brackets, springs or other tightly onto the treads or handrail at least with one hand.
- Page 5 Using the ladder – ladder unfolding 2) When opening the hatch, face the ladder at a distance equal to the length of the arm from the opening hatch. 1) Place the control rod in the lock opening and turn it left. The hatch drops down Do not stand under the hatch of the ladder when it is being opened as it may lead to an automatically by 20°.
- Page 6 Using the ladder – ladder folding 1) Hold the lower segment with both hands and slowly raise it. 2) Fold the ladder on the hatch by slowly placing each segment on top of the other. Do not hold the stringers at the point of the hinged connection between segments to avoid Do not hold the stringers at the point of the hinged connection between segments to avoid pinching your fingers.
- Page 7 Comments on use The control rod should be used only for opening and closing the hatch of the loft ladder. The hatch of the loft ladder should be opened and closed by slowly turning the lock with the control rod. The control rod should be kept out of reach of children.
- Page 8 Warranty 3 YEARS Service / Service after the warranty period Http://www.fakro.pl/serwis/index.php Email: serwis@fakro.pl...
