Summary of Contents for Kango K 200
- Page 2 Repair Instructions PAGE K 200 Special Tools Mandril (diameter 9.5 mm), approx. 100 mm long. Required Assembly support in which the tool can be fixed vertically. Important! Before beginning the maintenance work, perform an initial check with a high voltage test according to VDE (see chapter Electrical and Mechanical Test Instructions).
- Page 3 Repair Instructions PAGE K 200 Dismantling the Remove the axial needle bearing (4). reduction gear Take out the complete reduction gear, then remove the reduction gear shaft (8). Remove the needle bearing (2) and the sealing ring (1). Remove the sleeve (7), the pin (6), and the bearing (3).
- Page 4 Repair Instructions PAGE K 200 Dismantling the Unscrew and remove the service cover handle shells (2). Loosen the screws of the cable clip (5), re- move it and lay bare the power supply lead. Loosen the connectors (4). Unscrew and remove the housing (3).
- Page 5 Repair Instructions PAGE K 200 Maintenance General It is recommended to regularly submit the tool to maintenance, or as soon as the hammer mechanism gets weak, or when the carbon brushes switch off. When carrying out maintenance all parts of the maintenance set must be exchanged.
- Page 6 Repair Instructions PAGE K 200 Assembly Mounting the ar- Insert the armature (4) together with the mature field (5) into the housing. Mount the switch. Insert the brush holder insulations (1) and the brush holders (3) together with the car- bon brushes (2) into the housing.
- Page 7 Repair Instructions PAGE K 200 Mounting the Mount the needle bearing (1). cylinder Insert the sealing ring (6). Insert the snap die (2), the rubber ring, the washer,the spring ring, and the drill spin- dle (5). Insert the cylinder (3) as shown in illustra- tion.
- Page 8 Repair Instructions PAGE K 200 Mounting the Insert the spindle sleeve (8) into the gear gear box box. Fit the gear wheel (1). Insert the O-ring (3) together with the discs. Mount the gear switch lever (6) and the pin (7).
