- Page 1 User Manual 24 Inch 2-in-1 LCD Bar Display BW24A-AS Before connecting,operating or adjusting this product, please read the User Manual. Please keep this manual for future reference.
-
Page 2: Table Of Contents
Contents Warning and Precautions.............2-8 Wall Hanging Instruction............9-10 Accessories..................10 Buttons and Interfaces..............11 Specification.................12 Basic Operations..............12-14 1.Desktop..................12 2.Apps..................13 3.Setting..................13 4.ADB Function................14 Troubles Shooting..............15-16... -
Page 3: Warning And Precautions
Warning and Precautions Electricity can provide many useful functions, but improper use will also cause harm to personal and property security, both the design and manufacturing of this product are based on the highest require- ments of safety, improper use may cause harm, such as electric shock, fire damage, etc. - Page 4 6.Power supply The power supply utilized in this unit is marked on the power supply label. If you are not sure the power supply type in your area, please consult the local dealer or electric power company. To better protect the product, in the thunderstorm weather or when this unit is not utilized for a long time or when unattended for a long time, please unplug the power plug of this unit and disconnect the antenna,...
- Page 5 personnel. When the unit is damaged by the followings, the unit is needed to be repaired: the power cord or power plug is damaged; liquid splashed into or solid fell into the unit, the unit is exposed to the rain or damp environment or the unit is dropped. 11.Conditions requiring maintenance When any of the following conditions occurs, please pull the plug from the AC socket and contact the professional maintenance...
- Page 6 When the unit needs to be hung on wall or ceiling, please make sure to install according to the method provided by the manufactur- er. This concerns safety issues. 15.Holder Please utilize the wheelbarrow, foot rest, tripod, holder or table des- ignated by manufacturer or sold with the unit.
- Page 7 When moving the unit from a low temperature place to a high tem- perature place, water steam will be condensed, do not utilize in this case, otherwise it may cause fire, electric shock or other hazards. Please clean with dry cloth. Please remove the power cord before cleaning, do not utilize liquid cleanser or aerosol to clean this unit.
- Page 8 24.Pixel defects The LCD screen of this unit is a high-tech product, it can provide fine picture. Sometimes, some inactive pixels may appear blue, green or red fixed point on the screen, but that does not affect its performance. Remarks: when utilizing this product, the product's power plug must be connected to the power supply outlet with protective grounding.
- Page 9 FCC Warning: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause unde- sired operation.
-
Page 10: Wall Hanging Instruction
Wall Hanging Instruction Installation of wall hanging The LCD Display is already with Wall Hanging, which installed on the back cover. Step 1. Take out the Part1&Part2 as below Step 2. Put the right screws into the 5 locations on Part 1& Part 2 Step 3. -
Page 11: Accessories
Notes 1) Picture is only for reference 2) As for LCD Unit with terminal block, please use rubber pad and screw to fix wall hanging to provide enough space for terminal block. Accessories Please make sure the following items are included in your LCD Display Package. -
Page 12: Buttons And Interfaces
Buttons and Interfaces Introduction Interface Function DC IN Power supply the Display with Adaptor plug in ON/OFF Power ON/Power off the Display Reset the Display EARPHONE Connect one Earphone RJ45 Ethernet interface Micro SD Insert Micro SD card Connect U Disk or Mouse Connect Mouse or use ADB function Recovery Update software... -
Page 13: Specification
Specification Display size 24 Inch 2-in-1 Bar Display Resolution 1920*360 Brightness 300inits System Android 8.1 Storage 2GB RAM+8GB ROM Power Voltage 12V 4A 48W Interfaces DC in, Earphone, RJ45, Micro SD, USB, OTG, Recovery Buttons Power on/off, Reset Weight 6.3KG/pc Dimension 1228.5×134.5×36mm Basic Operation... -
Page 14: Apps
Apps In this screen, there are many apps, you can use functions as below pics. Setting 1.Connecting Network &Internet---searching the wifi nearby, and connect to the network 2.Connected Devices--can contacted other devices by Cast or OTG functions 3.Apps ¬ifications--can check which apps installed and uninstall apps. -
Page 15: Adb Function
5.Sound--can change the Volume, Vibration or Do not Disturb 6.Screenshot--can show the screenshot icon on taskbar 7.Storage--show the storage of used and free 8.System--choose the Language and keyboard layout 9.Date& Time-- set the Zone, date& Time 10.Backup--remove the data or factory reset ADB function 1.Enable OTG function on Display: Setting→Connected Devise→... -
Page 16: Troubles Shooting
SDK on PC. 3.Connect the Display OTG interface and PC USB port with USB cable. You can find one Android Device in PC Device Manager Trouble Shooting 1.Adaptor cannot work 1)Pls check whether connect the AC power cable to Adaptor 2)Pls check the Socket has Voltage or not 3)Pls check the Adaptor Plug and Power Cable connect correctly 2.The Bar Display cannot Display... - Page 17 3)Or change to another Mouse to try 6.The screens Display Abnormally 1)Both screens display Abnormally, pls reset the Machine first 2)One of Screen displays abnormally, pls connect Professionals to handle with it.
