Marvel MLBV024-SS01A Quick Reference Manual

Undercounter refrigeration

Advertisement

Quick Links

GE T TING STARTED
QUICK REFERENCE GUIDE
M ARVEL UNDERCOUNTER REFRIGERATION
M L B V 0 2 4 - S S 0 1 A
M L B V 0 2 4 - S G 0 1 B
M L W C 0 2 4 - S G 0 1 A
T H E O R I G I N A L R E F R I G E R AT I O N E X P E R T S S I N C E 1 8 9 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLBV024-SS01A and is the answer not in the manual?

Questions and answers

Summary of Contents for Marvel MLBV024-SS01A

  • Page 1 GE T TING STARTED QUICK REFERENCE GUIDE M ARVEL UNDERCOUNTER REFRIGERATION M L B V 0 2 4 - S S 0 1 A M L B V 0 2 4 - S G 0 1 B M L W C 0 2 4 - S G 0 1 A T H E O R I G I N A L R E F R I G E R AT I O N E X P E R T S S I N C E 1 8 9 2...
  • Page 2: Table Of Contents

    Important information to help assure a problem free installation and operation. Got a Marvelous Design? We would love to see how your Marvel product looks in its WARNING new home. Send us photos at marketing@marvelrefriger- ation.com, and we might feature your Marvel home design...
  • Page 3: Unpacking Your Appliance

    Keep your carton and packaging until your appliance has been thoroughly inspected and found to be in good condi- tion. If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. MARVEL WARNING XXXXXXXXXXXX XXXXXXXXXXXX WARNING -...
  • Page 4: Installing Your Appliance

    CAUTION floor and level from side to side and front to back. The over- all height of your Marvel appliance may be adjusted higher (by turning the leveling leg out, CCW) and lower (by turning Front Grille the leveling leg in, CW).
  • Page 5: Electrical

    ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be plugged into a mating grounding type receptacle in accor- dance with the National Electrical Code and applicable Do not remove local codes and ordinances (see Figure 6).
  • Page 6: Cutout And Product Dimensions

    CUTOUT & PRODUCT DIMENSIONS 23 ⁄ ” PREPARE SITE (608 mm) CAUTION Your product has been designed for either free-standing FRONT or built-in installation. When built-in, your unit does not 34 ⁄ ” 35 ⁄ ” 28” (867 mm (711 mm) require additional air space for top, sides, or rear.
  • Page 7: Door Adjustments

    16-1/2" 16-1/2" 90° 90° Door Swing Door Swing DOOR ADJUSTMENTS Black, White and Wood Overlay Stainless Steel 2175R(F) & 2275WC Models Grille Installation Door Swing Wall Wall REMOVING AND INSTALLING GRILLE 1/4" Min. 2-1/8" Min. (6 mm) (54 mm) WARNING WARNING ...
  • Page 8: Door Reversal

    DOOR REVERSAL Reversing the Door Remove and reinstall bottom hinge: Location of the unit may make it desirable to mount the 1. Remove bottom hinge from cabinet by removing three door on the opposite side of the cabinet. screws. The hinge hardware will be removed and reinstalled on the opposite side of the cabinet.
  • Page 9: Installing The Anti-Tip Device

    INSTALLING THE ANTI TIP DEVICE Anti-Tip Bracket NOTE 1. Slide unit out so screws on top of unit are easily accessible. If the room floor is higher than the floor in the cutout open- 2. Remove the two screws from the opposite side of the ing, adjust the rear legs to achieve a total unit rear height of hinge assembly using a T-25 Torx driver (see below).
  • Page 10 AIRLOW AND PRODUCT LOADING AIRFLOW NOTE External • Do not block the front grille - no additional clearance Restricting airflow may result in poor product performance, around sides, top or rear of unit is needed for ventilation product failure, and uneven internal temperatures and may freeze contents.
  • Page 11: Interior Adjustments

    INTERIOR ADJUSTMENTS INTERIOR SHELVES (MLBV024) Removing and Installing Interior Shelves Figure 27 For models equipped with glass shelves having recessed shelf supports, remove the shelves as follows: 1. Pull shelf out about 6” (1), until back of shelf clears the “hump” on the right-hand side. 2.
  • Page 12 INTERIOR ADJUSTMENTS Recommended Wine Storage (MLWC024) NOTE Wine bottles can be stored on the racks or bottom as shown. The racks are secured to the unit and are not designed to be removed. For your convenience, they are designed to pull forward approximately three inches.
  • Page 13: Using Your Electronic Control

    Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. Marvel recommends allowing the unit to reach set points before loading.
  • Page 14: Care And Cleaning

    WARNING  - Disconnect electric power to the unit For questions regarding winterization, please call before cleaning the condenser. Marvel Refrigeration at 616.754.5601 CAUTION Damage caused by freezing temperatures is not covered by NOTE the warranty.
  • Page 15: Obtaining Service

    800.223.3900 for directions on how to obtain warranty coverage in your area. • If the product is outside the first year warranty period, Marvel Customer Service can provide recommendations of service centers in your area. A listing of authorized service centers is also available at www.marvelrefrigeration.com under the...
  • Page 16: Warranty

    For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
  • Page 18 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle 30667 Rev A the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
