- Page 1 STATIC WATER LEVEL MEASUREMENT FLOW METER USER MANUAL www.enoscientific.com...
- Page 2 Eno Scientific 1606 Faucette Mill Rd Hillsborough, NC 27278 www.enoscientific.com 919-778-2660 Copyright Notice Copyright © 2010 Eno Scientific, Hillsborough, NC 27278, USA. All rights reserved. Part number: 128-2025...
-
Page 3: Table Of Contents
FLOW METER USER MANUAL TABLE OF CONTENTS PRODUCT OVERVIEW....................4 FLOW SENSOR OPERATING RANGE................5 FLOW SENSOR INSTALLATION: MECHANICAL............6 FLOW SENSOR INSTALLATION: ELECTRICAL............7 USING FLOW METER WITH THE WELL SOUNDER............ 8 USING FLOW METER WITH OTHER EQUIPMENT............. 9 SPECIFICATIONS......................10 WARRANTY AND SERVICE.................. -
Page 4: Product Overview
The output from the sensor unit can be plugged into an Eno Scientific Well Sounder for data collection and readout. It is designed to use very little power to conserve battery life. -
Page 5: Flow Sensor Operating Range
FLOW SENSOR OPERATING RANGE Eno Scientific flow sensors use a rotating impeller to sense the water moving through a closed pipe. As the water moves, it drags the paddles with it, producing a digital pulse as each paddle passes the sensor. Note that the pipe must be full for the impeller to accurately reflect flow. -
Page 6: Flow Sensor Installation: Mechanical
Water flowing too slow or too fast will not be measured accurately. Eno Scientific flow sensors measure flow over a range from 0.25 fps to 15 fps. It is important that the flow size be selected based on the flow rate to be measured and not the pipe size.The most common mistake in selecting a flow sensor is to oversize the unit and not be able to measure low flow. -
Page 7: Flow Sensor Installation: Electrical
FLOW SENSOR INSTALLATION: ELECTRICAL The flow sensor comes in two configurations: 1 – with a plugged cable for simple attachment to other Eno Scientific devices such as the Well Sounder. Installation is simple. Plug the cable into the compatible connector on the Well Sounder. -
Page 8: Using Flow Meter With The Well Sounder
Flow - displays the total water through the flow meter in gallons or liters if in metric mode. The total can be reset by pressing the ENTER button while viewing on the display. Eno Scientific Well Sounder 2010 / 2010 PRO Page 8... -
Page 9: Using Flow Meter With Other Equipment
The offset increases the accuracy in the operating range of the flow meter but also will yield a net flow when the flow rate is below the minimum or zero. Used to calculate total water pumped, this technique is not appropriate. Eno Scientific Well Sounder 2010 / 2010 PRO Page 9... -
Page 10: Specifications
7.11 x 5.75 x 3” Clearance for sensor removal: 3.5” Electrical: Power: 5 – 24V @ 500 uA max Output signal: Pull-to-ground (+V – 0V) Pulse width: ~5mS Frequency: .3 – 200 Hz Eno Scientific Well Sounder 2010 / 2010 PRO Page 10... -
Page 11: Warranty And Service
WARRANTY AND SERVICE Eno Scientific warrants to the user that all products manufactured by Eno Scientific, will be free from defects in workmanship and materials for 1 year from the date of shipment. Eno Scientific warrants to repair or replace any such defective equipment or part... - Page 12 Eno Scientific Well Sounder 2010 / 2010 PRO Page 12...
