- Page 1 KZ-5200EA-PRO-2S With Japan Walbro carburator KZ-6300EA-NEO-2S...
- Page 2 ■INTRODUCTION To correctly use the earth auger and prevent accidents, do not start work without having first carefully read this manual. You will find explanations concerning the operation of the various parts plus instructions for necessary checks and relative maintenance. Note: Illustrations and specifications in this manual may vary according to Country requirements and are subject to change without notice by the manufacturer.
-
Page 3: Parts Location
■PARTS LOCATION 1. Starter 2. Fuel Tank 3. Engine 4. Stop Button Comp 5. Throttle Lever 6. Grease Cap 7. Auger Bit... - Page 4 ■Understanding Safety Labels - This symbol indicates Warning, and Caution. - Your manual contains special messages to bring attention to potential safety concerns, machine damage as well as helpful operating and servicing information. PLEASE READ ALL THE INFORMATION CAREFULLY TO AVOID INJURY AND MACHINE DAMAGE. - Wear eye, hearing head protection when operating this equipment.
- Page 5 Warning to Users 1. The gasoline engine must use mixed fuel with volume rate of 30:1 for No.90 gasoline to two-stroke automobile oil. 2. 3 to 5 minutes’ low speed rotation after start and before stop is very necessary. In order to prevent damage of some parts or body harm caused by violent movement of the engine.
-
Page 6: Basic Safety Precautions
■SAFETY RULES 1、Basic Safety Precautions • Read this manual carefully until you completely understand and can follow all safety rules, precautions, and operating instructions before attempting to use the unit. • Restrict the use of your earth auger to adult users who understand and can follow safety rules, precautions, and operating instructions found in this manual. - Page 7 approved clothing. The use of protective clothing does not eliminate injury risks, but reduces the injury effects in case of accident. Consult your trusted supplier to choose equipment in compliance with legislation. The clothing must be proper and not an obstacle. Wear adherent anti-cut clothing. Protective jackets and dungarees are ideal. Do not wear clothes, scarves, ties or bracelets that can stuck into twigs.
-
Page 8: Fuel Handling
personnel. • The earth auger must only be used for making bores in soil. It is forbidden to cut other types of material. Do not use the earth auger as a lever to lift, move or break objects, nor lock it on fixed supports. It is forbidden to apply tools or applications that are not the ones indicated by the manufacturer onto the earth auger’s power take-off. - Page 9 • Tighten fuel cap securely after refueling. Unit vibration can cause an improperly tightened fuel cap to loosen or come off and spill quantities of fuel. • Wipe spilled fuel from the unit. Move 10 feet (3 m) away from refueling site before starting engine.
-
Page 10: Operation And Safety
3、Operation and Safety WARNING: Always hold the earth auger with both hands when the engine is running. Use a firm grip with thumbs and fingers encircling the earth auger handles. • Keep all parts of your body away from the earth auger when the engine is running. -
Page 11: Precautions To Reduce Vibration Risk
• Do not work near electric cables. WARNING – Contact with electrical cables or wires can cause serious injury or death as a result of electrical shock. This unit is not insulated. • Keep the handles dry, clean, and free of oil or fuel mixture. -
Page 12: Maintenance Precaution
vibrations transmitted to your hands. • Maintain a firm grip at all times, but do not squeeze the handles with constant, excessive pressures, take frequent breaks. All the above mentioned precautions do not guarantee that you will not sustain whitefinger disease or carpal tunnel syndrome. - Page 13 • Never use fuel for cleaning operations. • Keep the earth auger in a dry place, off the ground with the tanks empty. • If your earth auger is no longer usable, dispose of it properly without damaging the environment by handing it in to your local Dealer who will arrange for its correct disposal.
- Page 14 ■ASSEMBLY Fit the reduction shaft (C) into the seat on the bit (D) and secure it using the appropriate gudgeon pin (A)and（B）.
-
Page 15: Operation
■OPERATION 1、Before start (1) Promise the surroundings no man and animal; (2) Check the earth auger in detail，promise it in the safe appearance; (3) Beat the accelerator switch to the lowest position; (4) Have to make the earth auger with the adding-fuel place to keep at least 3m distance 2、Start (1)Put the stop button on the starting position;... - Page 16 The After start, the the start rope should be contracted back slowly with hand's help. If the rope contracts back fast, it may cause damage of the starter; (5)After start, put the choker slowly to full open position; (6)Regulate the fuel handle to a proper position to run at low speed for 3-5 minutes, then make spraying operation. New machine should not work at full open position within the first 4 hours.
- Page 17 ■MAINTENANCE ＆CARE 1、Periodical Check Cleaning •Clean the air filter element (1) frequently. 2、Check Spark Plug •Scrape off the carbon from the spark plug gap 0.6-0.7mm (.023".028") •Clean the cylinder exhaust port and muffler. •Inspect carefully for any fuel or oil leaks. •Lubricate Gear Case, every 25 hours of use.
-
Page 18: Failure To Start
■TROUBLE SHOOTING GUIDE 1. FAILURE TO START problem probable cause remedy Fuel system these is no fuel in tank add fuel in tank abnormality fuel filter obstruct clean fuel filter fuel is too dirty instead fuel spark plug there is water in fuel instead fuel spark normal fuel system... -
Page 19: Low Output
stop switch failure or short repair or replace circuit 2. LOW OUTPUT symptom probable cause remedy flameout when speedup fuel filter obstruct, clean fuel filter、clean fuel road、 the smoke is thin fall short of fuel adjust carburetor carburetor spout backward muffler fouled with oily deposits clean the oily deposits compress press is shortage... - Page 20 4. THE ENGINE SUDDENLY STOPPED spark plug fouled with oily deposits and short circuit clean the oily a t l s t i ■ SPECIFICATIONS Name/Type KZ-5200EA-PRO-2S KZ-6300EA-NEO-2S Net Weight Single Operation 520×340×360 Outward Size(No Bit) 670×360×440 Double Operation Power Transmission Method...
-
Page 21: Inspection And Maintenance
INSPECTION & MAINTENANCE For safety use, make sure the machine is cleaned every three-months. Before working, make sure to inspect the filter and the nozzle,and ensure there is no impurity. After working, make sure there is no water in the pump and the hose. If the machine needs to be repaired in the guarantee period, please return the machine to the shop. - Page 22 Warranty Card CUSTOMER COPY Product Name Date of Delivery Purchaser’s Name & Address KZ-5200EA-PRO-2S / KZ-6300EA-NEO-2S EARTH AUGER Dealer Sign Product Serial No. Dealer’s Office Seal Customer Sign. Invoice / DN No. I/We accept the terms and conditions of Warranty as in the Warranty Card.
- Page 23 1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement.
- Page 24 Dealer’s Office Seal & Signature Operations: • Check and Test the Fuel Mixture. KZ-5200EA-PRO-2S / KZ-6300EA-NEO-2S EARTH AUGER • Check and Clean the Air Filter • Check, Clean and Adjust the Spark plug • Check and Adjust the Carburetor Tuning...
