Living Spaces MADISON PARK Assembly Instruction

Hancock counter & bar stool

Important safety instructions:

Please carefully read all instructions before assembling.

For your safety and ease, assembly by two or more adults is recommended.

Keep instructions for future use.

Do not discard any contents until after assembly is complete to avoid accidentally discarding small parts or

hardware.

Remove all parts and hardware from box along with any plastic protective packaging.

Step 1. Assemble the stool on a flat, soft surface such as a carpet or cloth to prevent scratching the finish.

1) Attach one leg (P2) to the bottom of chair top (P1) using bolts (H1), lock washers (H2) and flat washers (H3).

2) Insert one stretcher (P3) between the two legs (P2), then attach leg (P2) to the bottom of chair top (P1) using

bolts (H1), lock washers (H2) and flat washers (H3) as shown below.

(H1)x4

(H2)x4

(H3)x4

(H4)x1

Table of Contents

Do you have a question about the MADISON PARK and is the answer not in the manual?

Page 1 Important safety instructions: Please carefully read all instructions before assembling. For your safety and ease, assembly by two or more adults is recommended. Keep instructions for future use. Pre-assembly: Do not discard any contents until after assembly is complete to avoid accidentally discarding small parts or hardware.
Page 2 Step 2. Loosely Insert front stretcher (P4) between the two legs (P2), then attach the third leg (P2) to the bottom of chair top (P1) using bolt (H1), lock washer (H2) and flat washer (H3) as shown below. (H1)x2 (H2)x2 (H3)x2 (H4)x1 ADDITIONAL NOTE ABOUT SAFETY: BOLTS MAY LOOSEN DURING NORMAL EVERYDAY USE.
