Unpacking and Setup
Open the shipping carton of LinkStation and carefully unpack its contents. The
carton should contain the following items:
Main unit (LinkStation)
LinkStation Base Plate
Base Rubber Feet
Ethernet Cable
Power Cord
LinkNavigator Installation CD
Quick Setup Guide (this user's guide)
Warranty card
If any items are missing or damaged, please contact the reseller or retailer from
which the product was purchased.
The front face of the LinkStation has a protective plastic fi lm covering for
protection from scratching during assembly and shipping. The fi lm may be
removed by peeling it away from any corner of the front face.
Quick Setup Guide
www.buffalotech.com
Gigabit LinkStation
HD-HGLAN Series
1
1
4
1
1
1
1
1
v2.6
