Summary of Contents for HANNspree HL407UPB
- Page 1 HL407UPB (HSG1348) LCD Monitor...
- Page 2 Electromagnetic Compatibility, and 2014/35/EU and 93/68/EEC with regard to Low Voltage directive. Socket-outlet shall be near the equipment and shall be accessible. Trademark Notice: HANNspree products incorporate High-Definition Multimedia Interface (HDMI ) technology. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 3 User’s Manual RECYCLING INFORMATION We, the HANNspree care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels.
-
Page 4: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ....................5 PRECAUTIONS....................5 SPECIAL NOTES ON LCD MONITORS ............6 BEFORE YOU OPERATE THE MONITOR ............7 FEATURES......................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 INSTALLATION INSTRUCTIONS ..............8 POWER....................... 8 SETTING THE MONITOR ON THE WALL .......... -
Page 5: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 6: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. -
Page 7: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 100,3cm / 39.5” Wide Screen TFT Color LCD Monitor Crisp, Clear Display Ergonomic Design Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: LCD Monitor Cables and User manual HDMI Cable... -
Page 8: Installation Instructions
User’s Manual INSTALLATION INSTRUCTIONS INSTALL & REMOVE Figure.1. Installing and Removing the Base Put machine flat on working table. Install base in machine bottom of back cover as arrow direction, and make the positioning hole on top of V cover of base aligned with the positioning raised stand on the bottom of machine back cover, then fasten screw.(The base has to be adjusted to figure state, otherwise base cannot be installed in.) Remark: The actual base and machine appearance may be different from pictures;... -
Page 9: Setting The Monitor On The Wall
*Installing the LCD Monitor requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. HANNspree bears no responsibility for improper mounting or mounting that results in accident or injury. You can ask a... -
Page 10: Making Connections
User’s Manual MAKING CONNECTIONS CONNECTING TO A PC Turn off your computer before performing the procedure below. Remark: The peripheral equipment and cables described in this manual should be purchased separately. -
Page 11: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. - Page 12 User’s Manual NOTES: Do not install the monitor in a location near heat sources such as radiators or air dusts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock. Save the original shipping box and packing materials, as they will come in handy if you ever have ...
-
Page 13: Remote Control
User’s Manual REMOTE CONTROL Installing battery Remove the battery cover, and insert two AAA(1.5V) batteries; make sure that the polarity of the battery is consistent with the marks” +/-“ in the battery slot. Precautions of remote control usage ● Point the remote control to the receiver window. The objects between remote control and the receiver window may disturb the normal operation. -
Page 14: How To Adjust A Settings
User’s Manual HOW TO ADJUST A SETTINGS Press “MENU” key on the remote control or on the control Panel, then the TV will display the main menu. 1. Press “◄/►” key on the remote control or ▲/▼ key on the control panel to select the adjustment sort menu, which includes 3 sorts: PICTURE , SOUND, OSD. - Page 15 User’s Manual Remark : The values of Contrast , Brightness, Hue , Saturation and Sharpness adjusted by the user will be saved automatically. SOUND Sound Mode Select the audio mode：Standard , Music , Movie , User . Adjust the treble: increase the analog value to increase the treble Treble and decrease the analog value to reduce the treble (0-100).
-
Page 16: Plug And Play
User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 17: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position. Power LED is on *Power Cord should be connected. *Check if the PC system is Plug & Play compatible. *Check if the Video Card is Plug &... - Page 18 68,6cm / 27 ” (16:9) 70cm / 27.5” (16:10) 1920×1200@60Hz 1920×1200@50Hz 100,3cm/39.5”(16:9) 1920×1080@60Hz 1920×1080@60Hz And if you still have display problem after doing the above procedure, please visit HANNSpree support and Service Website: http://www.hannspree.eu/en/monitors Windows is a registered trademark of Microsoft Corporation.
-
Page 19: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED: 1. Check that the signal-cable is properly connected, if the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. -
Page 20: Appendix
5.8 kg (12.8 lb) *** The above specification is subject to actual product specification and is subject to change without prior notice. NOTES: The Maximum Resolution will depends on the display card supporting. Related issue can refer to http://www.hannspree.eu/en/monitors. FAQ section.
