  • Page 1 Instruction Manual Mini Single Sheet Tester SY-956...
  • Page 2 Ⓒ 2014_2015 IWATSU TEST INSTRUMENTS CORPORATION．All rights reserved．...
  • Page 3 ◇ FINEMET is a registered trademark of Hitachi Metals, Ltd. It shows as follows in this manual. ◇ If any question about this product arises, contact Iwatsu at the address listed at the end of this manual or our sales distributors.
  • Page 4 (〇 side), and remove the power plug from the receptacle. Then contact Iwatsu office or our sales distributors for repair. Do not attempt to repair this product yourself. ● Make sure no water gets on or inside this product.
  • Page 5 ● Strictly observe items below when handling the power cord. If not, an electric shock or fire may occur. If the power cord is damaged, contact Iwatsu office or our sales distributors for repair.  Do not modify the power cord.
  • Page 6 ● Do not use this product when being failed. If not, an electric shock or fire may occur. For a failure, contact Iwatsu office or our sales distributors for repair.
  • Page 7 The power cord and cable may be damaged causing a fire or electric shock. ● Never replace the fuse inside the main unit. Contact Iwatsu office or our sales distributors for replacement. ● Use 3-core power cord in accordance with the power supply voltage.
  • Page 8 If there is not a proper packing material/ shock absorber, contact Iwatsu office or our sales distributors. When having this product transported by a shipping company, write "Precision Instrument - Handle With Care"...
  • Page 9 If there is a lacked item or an item damaged during transportation, immediately contact Iwatsu office or our sales distributors. Components Mini Single Sheet Tester SY-956 main unit ......1 Accessories Mini Single Sheet Tester cable (SY-957) ......1 B Coil 01 (SY-958) ............
  • Page 10 If a failure occurs, mail this product to our service center. Any failure which occurs within the term of warranty and for which Iwatsu is responsible should be repaired without any cost. When shipping a product to be repaired, clearly write the product name, serial number (in the label on the rear of this product), description of the failure, and name, division, and telephone number of the responsible person.

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 Introduction ............................... 2 ■1.1 Summary ................................ 2 ■1.2 Features ................................. 2 ■1.3 Cautions for handling and installation ......................3 Chapter 2 Before Measurement ..........................4 ■2.1 For proper measurement ..........................4 ■2.2 Differences in measured values among Epstein frame, conventional SST, and this instrument....5 ■2.3 How to find the detection limit ........................

  • Page 12: Chapter 1 Introduction

    This instruction manual explains only about those functions of the B-H Analyzer that are added by operation and use of a Mini Single Sheet Tester SY-956. Descriptions of the functions that overlap with the standard functions equipped with the B-H Analyzer are omitted. Please refer to the B-H Analyzer’s instruction manual.

  • Page 13: Cautions For Handling And Installation

    ■ 1.3 Cautions for handling and installation ● Do not touch the measuring yoke of this instrument with your bare hands. ® The measuring yoke is made of FINEMET . Touching the measuring yoke with your bare hands may cause it to rust, resulting in incorrect measurements.

  • Page 14: Chapter 2 Before Measurement

    Chapter 2 Before Measurement There are several points users need to know before taking measurements with this instrument. ■ 2.1 For proper measurement ● In order to correctly measure and evaluate samples made of a variety of materials, there are things to be aware of other than excitation conditions.

  • Page 15: Differences In Measured Values Among Epstein Frame, Conventional Sst, And This Instrument

    [Measurement Example of the Influence of Air-Gaps] Figure 2-3 shows a B-H curve of a 0.35 ×3.0 ferrite slab. The blue curve shows the measurement of a B Coil with the hole size of 32.5 [mm ]. The yellow curve shows the measurement of a B Coil with the hole size of 82.5 [mm This shows how the saturation magnetic flux density and amplitude permeability change due to the influence of the...

  • Page 16: How To Find The Detection Limit

    each other, if each measurement device is ideally tuned. For example, it is implausible that a sample that shows the highest core loss with one type of measurement device shows the lowest core loss with another type of device. In order to conduct accurate measurement, it is important to use a testing device with high measurement accuracy.

  • Page 17: Measurement Principles

    ■ 2.5 Measurement principles Fundamentally, this instrument employs vertical single-yoke type, magnetizing current (MC) method-based single sheet testing. The biggest drawback of a conventional MC method-based SST has been the inclusion of the measuring yoke-related core loss in the core loss of a sample. In other words, a conventional MC method- based SST measures the properties of a soft magnetic composite material core that is made up of 2 materials: the sample itself, and the yoke.
  • Page 18 Therefore, H (4). Magnetic flux density B inside a single sheet is ∫ V (5). A conventional MC method-based SST is equivalent to measuring the iron loss P per unit volume of a single . (Whenever “iron loss” is indicated hereafter, it mean iron loss per unit volume.) sheet from this H and B Because iron loss P is determined by dividing the area of the B-H curve by the cycle of the excitation signal,...
  • Page 19 Since the excitation current sent through the excitation coil of the measuring yoke is the same for the 1st and 2nd measurements; B derived in the 2nd measurement is, in fact, the magnetic flux density of the magnetic field strength H in the measuring yoke from the 1st measurement.
  • Page 20 In conclusion, by substituting H of formula (12) into the first term of formula (7), (13), ∫ H the actual iron loss of only the single sheet P can be calculated. Yoke Comp. comes into effect when Yoke Comp. is Enabled, as explained in 4.15. When Yoke Comp. is Disabled, testing is completed after the 1st measurement.

  • Page 21: Chapter 3 Names And Functions Of Each Part

    Fig. 3-1 Front Panel of SY-956 (1) Main power switch Main power switch of a Mini Single Sheet Tester SY-956. (2) Slider position No. table From the thickness of the sample sheet and the desired force with which the slider presses the sample, determine the setting value of the slide position No.

  • Page 22: Fixture

    (6) B coil jack (1) Pole faces of the measuring yoke (5) B coil holder Fig. 3-2 Fixture of the SY-956 (1) Pole faces of the measuring yoke Place the measuring sample single sheet on these faces. Do not touch the pole faces with your bare hands. The measuring yoke may rust, resulting in incorrect measurements.

  • Page 23: Rear Panel

    Tester Cable SY-957 (2) POWER INPUT (1) Power input terminal Security seal Fig. 3-3 Rear panel of SY-956 (1) Power input terminal Insert the power cord. (2) POWER INPUT Connect the output from the power amplifier with the BNC cable.

  • Page 24: Chapter 4 Measurement

    Chapter 4 Measurement ■ 4.1 Flow before measurement ● The flowchart below shows procedures for the measurement with a Mini Single Sheet Tester SY-956. Startup → Measurement procedures End procedures Connect the B-H Analyzer and a Mini Turn off the power amplifier Single Sheet Tester SY-956 (See sec.

  • Page 25: Connecting Equipment

    ● The following shows how to connect the measuring equipment that integrates a Mini Single Sheet Tester SY-956. Mini Single Sheet Tester SY-956 needs to be connected to the B-H Analyzer with which it has been calibrated together. Proper measurement cannot be made by connecting to any other B-H Analyzers.

  • Page 26: Connecting Mini Single Sheet Tester Cable Sy-957

    ■ 4.3 Connecting Mini Single Sheet Tester Cable SY-957 ● The following shows how to connect the provided Mini Single Sheet Tester Cable SY-957. (1) Make sure the B-H Analyzer is turned OFF. (2) Remove the measuring terminal block from the POD.
  • Page 27 (5) After making sure the terminal block is properly installed on the measuring POD, secure the terminal block on the measuring POD with 2 provided thumbscrews. (See Fig. 4-7) (6) Attach the measuring connector of the Mini Shingle Sheet Tester Cable SY-957 on the back of (5) Hold the terminal block in the product.

  • Page 28: Powering On

    ■ 4.4 Powering on ● The following is the method to power on this instrument. (1) Turn on the main power switch of this instrument. (2) While the cover is closed, verify that the LEDs of the RELEASE button and SET button stop blinking and stay on.

  • Page 29: Attaching And Detaching A B Coil

    ■ 4.6 Attaching and detaching a B Coil (2) Gradually press the 4 edges of the B Coil from above. ● The following is the method of attaching and detaching a B coil. (1) Hold the cover handle and open the cover of this instrument.

  • Page 30: Measurable Samples

    ■ 4.7 Measurable samples ● Table 4-1 shows the sizes of measurable samples Table 4-1 Measurable sample size and specifications of the provided B coils Measurable sample sizes Size of the bobbin [mm] hole [mm] Number Types of B coils of Turns Thickness Width...

  • Page 31: Setting A Sample

    ■ 4.8 Setting a sample ● Following shows how to set a sample. Place the sample so that it sticks out symmetrically. (1) Remove dust from the pole faces of the measuring yoke with the provided blower brush. Make sure no dust or dirt is on the sample.

  • Page 32: Confirmation Of Functions

    4.11 Confirming POD ● Confirm the POD to conduct single sheet testing. (1) Press and display the Configuration screen. (2) Confirm that Setting of Equipment > Pod is SY-956 (Single Sheet). (See Fig. 4-17) (3) Press to close the Configuration screen.

  • Page 33: Measurement Screen

    ■ 4.12 Measurement screen ● Below is a summary of the single sheet testing mode screen. (1) Sample Parameters (4) Select (2) Excited Conditions (5) Cursor Values (3) Mode (6) Measured Values (8) Configurations (7) Graph Fig. 4-18 Measurement screen (1) Sample Parameters: Set and/or display the sample name, sample constant, and the type of the B coil.

  • Page 34: Input/Selection Of Sample Constant

    ■ 4.13 Input/selection of sample constant ● Input or select sample constant of a measuring sample. (1) While referring to Table 4-4, move the edition cursor to Edit Box of the sample constant to be entered in Sample Parameters and press to confirm the selection.

  • Page 35: Setting Measurement Conditions

    ■ 4.14 Setting measurement conditions ● Set the measurement conditions. (1) While referring to Table 4-5, move the editing cursor to the Edit Box of the measurement condition to be entered in Excited Conditions and press to confirm the selection. (2) For those with a Popup List that opens, move the editing cursor to a suitable item and press confirm the settings.

  • Page 36: Measurement

    ■ 4.15 Measurement ● Take measurements. Different measurement processes and displays are applied depending on whether the Yoke Comp. is Disabled or Enabled. [When Yoke Comp. is Disabled] to start measurement. A blinking message “Measuring!” appears on the screen. (1) Press (2) When the measurement has been completed successfully, the message “Measuring!”...
  • Page 37 Fig. 4-19 1st Measurement Screen Fig. 4-20 3rd Measurement Screen...

  • Page 38: Switching Graphs

    ■ 4.16 Switching graphs ● Similar to the normally installed testing modes, the displayed graph can be switched to a B-H graph or a time axis graph. Please refer to the B-H Analyzer’s instruction manual for the operation. ■ 4.17 Cursor measurement ●...

  • Page 39: Chapter 5 Maintenance

    5.2 Calibration ● Measurement accuracy and precision of this instrument may fluctuate with long-term use, depending on the environment or frequency of its operation. Calibration at least once a year is recommended. For details, contact Iwatsu office or our sales distributors.

  • Page 40: Chapter 6 Specifications

    Chapter 6 Specifications ■ 6.1 Specifications Table 6-1 Specifications Items Specifications Power supply voltage AC 100 V to 240 V Power Frequency range 50 Hz/60 Hz Power consumption 27 VA (Max.) Vertical single-yoke type, magnetizing current (MC) method-based single sheet Measurement method testing (similar to IEC 60404-3) (with Yoke Comp.

  • Page 41: Outside Appearance Diagram

    ■ 6.2 Outside appearance diagram Unit: mm...

  • Page 42: Outside Appearance Of The Fixture

    ■ 6.3 Outside appearance of the fixture Unit: mm...
  • Page 43 Address 7-41 Kugayama 1-chome Suginami-ku Tokyo, 168-8511 Japan Phone +81 3 5370 5483 Facsimile +81 3 5370 5492 Homepage http://www.iti.iwatsu.co.jp...
  • Page 44 SY-956...
