220
RECHARGEABLE
COB LED
INSPECTION
LAMP
1. EQUIPMENT OVERVIEW
1. Hook
2. Transparent LED cover
3. 3W COB LED
4. Switch
5. Charger indicator
6. Charger socket
7. Magnetic Strip
8. Car charger
9. USB AC charger
10. USB cable
2. OPERATION GUIDE
1.CHARGING
Connect the charger into charging socket (6)
which is located on the rear of worklight.
Connect the USB charger or car charger to a
power supply. The charging indicator (5) will
illuminate to show the charging has started.
NOTE: The charging indicator will turn
green when the lamp is fully charged.
Disconnect the charger from the worklight when
it has been charged for a sufficient time.
2. OPERATION
Press the control switch (4) and choose a
work mode suitable to your surroudings.
There are two modes: (1) High (2) Low.
The lamp can be fixed / attached to ferrous
metal by use of the magnetic strip (7).
FEATURES
Slimline rechargeable COB LED worklight
Hanging hook and robust magnetic casing for versatility & hands free use
2 brightness levels: 160/220 Lumens output
3.7V 1900mAH LI rechargeable battery
With AC/DC chargers (230V & 12V)
5hrs runtime on full battery charge
www.jeffersontools.com
3. GENERAL SAFETY
This device utilizes rechargeable Lithium ion
battery that can rupture, ignite and cause series
injury if missued or disposed of incorrectly.
Observe the following safety rules:
•
DO NOT place battery and device
in fire or high temperature
•
DO NOT tamper with the battery wiring
•
DO NOT puncture or damage the battery
•
DO NOT use a battery that appears to be damaged
•
DO NOT immerse or expose the battery to water
•
DO NOT alter or modify the battery
•
DO NOT attempt changing the battery in any
manner other than that prescribed in this manual.
•
DO NOT dispose of the battery in fire or water.
•
Failure to heed these warning may result in
personal injury and/or property damage.
CAUTION: Never shine the LED light directly into
eyes as the LED is extremely bright and may cause
injury if used incorrectly or inappropriately.
JEFTRCH09ILSG
User Manual
v.1.1
