OPERATING INSTRUCTIONS

Fire Hazard
No washer can completely remove oil.
Do not dry anything that has ever had any type of
oil on it (including cooking oils).
Items containing foam, rubber, or plastic must be
dried on a clothesline or by using an Air Cycle.
Failure to follow these instructions can result in
death or fire.
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Do not dry anything that has ever had anything
flammable on it (even after washing).
Failure to follow these instructions can result in
death, explosion, or fire.
WARNING: To reduce the risk of fire, electric shock, or injury to persons, read
the IMPORTANT SAFETY INSTRUCTIONS, located in your appliance's
Owner's Manual, before operating this appliance.
STEP 1. CLEAN LINT SCREEN STEP 2. LOAD CLOTHES
STEP 3. PRESS POWER STEP 4. SELECT THE
BUTTON DESIRED CYCLE FOR YOUR LOAD*
STEP 5. ADJUST CYCLE STEP 6. PRESS, HOLD, AND
SETTINGS AND OPTIONS, IF RELEASE START BUTTON
DESIRED
NOTE: Start button must be held for
1 second to start cycle. Once the
status lights are illuminated, release the
start button.
*Not all cycles, settings or options are available with all models.
QUICK START GUIDE
WHIRLPOOL DRYER
®

CONTROL PANEL AND FEATURES

*Not all features, cycles, and options are available on all models. Appearance may vary.
POWER
1
Press to turn on/off or to stop/cancel a cycle.
2 CYCLE KNOB
Turn knob to select desired cycle.
NOTE: Your dryer comes with two types of cycles - Sensor drying
cycles and Timed drying cycles.
SENSOR DRYING CYCLES:
Use Sensor Cycles for better fabric care and energy savings.
The dryer senses moisture in the load or air tem perature and
shuts off when the load reaches the selected dryness level.
Note that you cannot adjust the time with these cycles.
TIMED DRYING CYCLES:
In these cycles, you can specify the drying time. Time options
available are 15, 30, 60 and 90 minutes. For a complete list of
all cycles, please refer to the cycle guide document.
3
START/PAUSE
Press and hold the Start/Pause button for 1 second until all
status lights are illuminated, then release to start cycle. Press during
a cycle to pause cycle.

CHOOSING THE RIGHT CYCLE

A cycle guide for your dryer can be
found online at
www.whirlpool.com. The
document will help identify which
cycle to choose for various load
types as well as the default cycle
options. For example we recommend
using the NORMAL cycle with
Medium temperature for cottons,
linens and mixed-garment loads.
For detailed installation instruction and maintenance information, winter storage, and transportation tips, please see the "Owner's Manual" included
with your machine.

ASSISTANCE OR SERVICE AND ADDITIONAL INFORMATION

For information on any of the following items, a full cycle guide, detailed product dimensions, or for complete instructions for use and installation,
please visit www.whirlpool.com/owners, or in Canada www.whirlpool.ca/owners. This may save you the cost of a service call.
Register Schedule Service
Product
Model &
Serial
Number
Tag Location
2
4
CYCLE MODIFIERS (Not all modifiers are available on all cycles)
TEMP
Press to modify the cycle's available temperature. (Extra Low, Low,
Medium, and High)
TIME (Air Only, Timed Dry, and Quick Dry Only)
Press to modify the time for the timed cycle between 15, 30, 60,
and 90 minutes.
OPTIONS
Press to add or remove options for each cycle. Press once to
activate Wrinkle Shield, twice to activate Static Reduce and three
times for both.
WRINKLE SHIELD
If you will be unable to remove a load immediately, activate
this option to add 150 minutes of periodic tumbling to help
reduce wrinkles from forming after the cycle completes.
STATIC REDUCE
This option can help reduce the build up of static cling formed
during the drying process. When activated, this option will
tumble with steam towards the end of the cycle to reduce
static.
MUTE CYCLE SIGNAL
Use this option to turn the end of drying cycle signal on or off.
SPECIALITY CYCLE
WRINKLE CONTROL:
This cycle is designed to help remove or reduce wrinkles, this cycle is
great for permanent press clothing. The dryer cycle uses low heat and
a cool down period to keep clothes from wrinkling or creasing.
STEAM REFRESH:
This cycle is best for reducing wrinkles and odors from dry items. This
cycle is great to refresh a wrinkled garment or when a load was left in
the dryer too long.
How To's & Manuals & Add Service
FAQ Downloads Plan
To speak with a customer service representative or if you have additional questions, call us toll free at
1-866-698-2538 or in Canada call 1-800-807-6777.
You can write with any questions or concerns at:
Whirlpool Brand Appliances
Customer eXperience Center
533 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
1
3
4
Parts Accessories
Whirlpool Brand Appliances
Customer eXperience Center
Unit 200-6750 Century Ave
Mississauga, Ontario L5N 0B7
