Status Light
Camera
PIR
Reset
Power Port
Power on/off
Status light
SD card slot
Reset
Charging
indicator
Battery capacity
RET
DC 5V±10%
Press the button for 3 seconds to turn on/off the camera
Red light solids on: the camera network is abnormal
Red light blinks: awaiting WiFi connection, or currently
connecting (faster blinking)
Blue light solids on: camera running correctly
Support local SD Card storage (Max.128G)
Press and hold on for 5 seconds to reset the camera
Red indicator solids on: battery is charging
Blue indicator solids on: charging completed
6700mAh (Two 18650 lithium-ion batteries)
Microphone
Speaker
Power button
Micro USB
SD card slot
SD
2
Advertisement
Table of Contents
Related Manuals for Meari Snap 8
Summary of Contents for Meari Snap 8
- Page 1 Microphone Status Light Speaker Camera Power button Micro USB Reset SD card slot Power Port DC 5V±10% Power on/off Press the button for 3 seconds to turn on/off the camera Status light Red light solids on: the camera network is abnormal Red light blinks: awaiting WiFi connection, or currently connecting (faster blinking) Blue light solids on: camera running correctly...
- Page 2 Install Mode 1 Bottom Bracket Installation 1.Fix the bracket to the wall with the mounting screws 2.Install the camera in the bracket and lock it with the screw Mode 2 Side Bracket Installation 1.Fix the mounting bracket in the angle wall mount 2.Fix the angle wall mount to the wall 3.Install the camera in the bracket and lock it with the screw...
