Brunton SolarRoll User Manual

S O L A R R O L L
Flexible Solar Panel
Panneau Solaire Souple
Product Specifi cations:
The SolarRoll is a fl exible solar panel that produces 14 watts, 9 watts, or 4.5 watts of power with a
loaded current and voltage of 15.1V*. This product offers reverse current protection. The SolarRoll
is designed to operate in a temperture range of -22°F to +122°F (-30°C to +50°C)
The SolarRoll consists of photovoltaic cells and will produce power when any of these segments
are exposed to sunlight. This means that you can partially unroll the panel and still utilize the pow-
er provided. Each segment produces an average of 50mA. To calculate the amount of power your
panel will produce when partially unrolled, count the number of segments that you have rolled
out and then multiply by 50mA. The voltage stays the same when rolled out entirely or partially.
Fully extended, the SolarRolls produce 900mA, 600mA, or 300mA, depending on wich SolarRoll
you own. They can also be linked to other SolarRolls of the same wattage to double the current
output. Due to the amount of current present, we recommend that no more than three panels be
put in a series at one time.
The SolarRoll is waterproof and can be submerged all the way up to the electrical connectors and
not be damaged. Avoid getting the electrical outlets wet. This could cause a direct short of the
panel and may permanently damage your product. Use caution when using any electrical appli-
ance.

Positioning:

Unroll the SolarRoll with the photovoltaic cells facing up or secure the panel in place with the
grommets provided around the exterior edge of the panel. For best results position the panel so
that it can receive the maximum amount of sun exposure. Plug into the panel with the cables pro-
vided. The SolarRoll can be left plugged into any device overnight without it draining the battery
because of the built-in reverse current protection.
*
SolarRoll 14 (15.1V, 900mA.) SolarRoll 9 (15.1V, 600mA.) SolarRoll 4.5 (15.1V, 300mA.)
