11. Tool Support
12. Shoulder Strap
13. Ejection Mechanism
14. Latch
15. Battery Release Button
16. Wrench Holder
17. Combi Wrench
ASSEMBLY
WARNING:
If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING:
Always remove the battery pack from
the product when you are assembling parts, making
adjustments, cleaning, or when the product is not in use.
ATTACHING AN ATTACHMENT TO THE TELESCOPIC
POWER POLE
WARNING:
Read and understand entire Operator's
Manual for each optional attachment used on this
telescopic power pole and follow all warnings and
instructions. Failure to follow all instructions could result
in electric shock, fire and/or serious personal injury.
WARNING:
This 56V telescopic power pole
PPX1000 is designed to be used only with the EGO
attachment models that are specified in this Operator's
Manual or subsequently introduced by EGO for use with
this telescopic power pole. Use of other, unauthorized
attachments could cause serious personal injuries or
property damage.
WARNING:
Never install, remove, or adjust any
attachment while the telescopic power pole is running or
with the battery installed. Failure to stop the motor and
remove the battery can cause serious personal injury.
The attachment connects to the telescopic power pole by
means of a coupler device.
1. Stop the motor and remove the battery pack.
2. Loosen the locking knob.
3. Align the arrow on the attachment shaft with the
aligning indicator on the coupler and push the
attachment shaft into the coupler until you hear a
clear "click" sound, the coupler should be positioned
all the way to the reference line on the shaft that the
attachment shaft is properly mounted into place. (Fig.B).
4. Pull the shaft of the attachment to verify that it is
securely locked into the coupler. If not, push the
attachment shaft in the coupler until it snaps into
place.
5. Tighten the locking knob securely.
fully tightened before operating equipment; check it
periodically for tightness during use to avoid serious
personal injury.
REMOVING THE ATTACHMENT FROM THE
TELESCOPIC POWER POLE
1. Stop the motor and remove the battery pack.
2. Loosen the locking knob.
3. Press the shaft-release button, with the button
MOUNTING THE SHOULDER STRAP (Fig. C)
Depress the strap hook to open it and attach it onto the
carrying eyelet.
EXTENDING TELESCOPIC TUBE
The tool is equipped with a telescopic tube that will
extend to 960 mm (fully extended).
The clamping knob is used to hold the telescopic tube in
position at any extended length.
1. To extend the telescopic tube, loosen the clamping
2. Pull the telescopic tube out to desired length of
3. To locking the telescopic tube in position, tighten the
please cautiously watch out in every step

OPERATION

to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
so could result in objects being thrown into your eyes and
other possible serious injuries.
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
56 VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000
WARNING:
Be certain that the locking knob is
depressed, pull the attachment shift out of the coupler.
knob by following its unlock icon. The telescopic will
slide freely (Fig. D)
extension.
clamping knob by following its lock icon.
WARNING:
In case of pinching your hand or fingers,
WARNING:
Do not allow familiarity with this product
WARNING:
Always wear eye protection. Failure to do
WARNING:
Do not use any attachments or
EN
