- Page 1 User Manual...
-
Page 3: Table Of Contents
Cool-Spot in operation Table of contents: Cool-spot display operations ......................Clarification of Cool-Spot controls, operation and side-effects ........Side-effects of Cool-Spot usage in various circumstances ..........Attention! Display notifications, explanation and desired actions ........FAQ - Troubleshooting ........................Tips for achieving the maximum cooling effect .............. -
Page 4: Cool-Spot Display Operations
Cool-Spot in operation 1. Cool-Spot Display Operation Cool-Spot is operated with the following buttons: Displays Cool-Spot is off: The display is dark, ® Cool Spot "Off" is displayed in the left corner. Activating Cool-Spot: Tap the (on/off symbol). The system is now booting. -
Page 5: Clarification Of Cool-Spot Controls, Operation And Side-Effects
Cool-Spot is Fresh stays Fresh The Cool-Spot climate for preserving fresh products is now being created by a mix of vapour and cold air. The area above the buffet or work surface is chilled to a temperature below 7°C with maximum air humidity. -
Page 6: Side-Effects Of Cool-Spot Usage In Various Circumstances
Whether or not and to what extent condensation will form, depends on the ambient air humidity and cannot be prevented. If the condensation becomes a nuisance during Cool-Spot operation, it can be wiped off with a cloth. How to remove water drops emerging on the exhaust nozzles: Getting the chilled climate to maximum humidity requires little vapour. - Page 7 The effect of draught near the Cool-Spot: The Cool-Spot climate consists of a mix of cold air and vapour and is transferred to the buffet or work surface as gently as possible. It essentially floats over the buffet to the edge of the surface.
-
Page 8: Attention! Display Notifications, Explanation And Desired Actions
Action: Replace or clean the condensation water pump. FRESH TECHNOLOGY Backup condensate pump: Cool-Spot has a backup condensate pump next to the main con- ® Cool Spot densate pump: If the main condensate pump fails or overflows, the Attenti on Level backup pump takes over this function. - Page 9 Cool-Spot in operation 4. Attention! Display notifications, explanation and desired actions Displays Interim Defrost Cycle: The refrigeration unit has become partially frozen, reducing the ® Cool Spot amount of cold air on the top. System only temporarily switches A ttenti on I nteri m off the refrigeration unit.
- Page 10 Cool-Spot in operation 4. Attention! Display notifications, explanation and desired actions Displays No water pressure in RO water filter system: This message appears on the display in combination with the ® CoolSpot message Vapour system is being filled. Attenti on...
-
Page 11: Faq - Troubleshooting
Cool-Spot Service you, or your own Technical Department, should first check a number of things, to see whether you could easily fix the fault yourself. The Cool-spot site also has a number of maintenance procedures for Cool-spot components under the Downloads button. -
Page 12: Tips For Achieving The Maximum Cooling Effect
Turn on the system a few minutes before the presentation session. When the Cool-Spot is switched on, the unit top will still be at the same temperature as the room, and it will take some time before the “warm” top itself has cooled down. -
Page 13: Mi-Light Led Control
Cool-Spot in operation 7. Mi-light LED control Indicator light Color ring Brightness - Brightness + Master ON Master OFF Speed - Speed + Zone on Modes (programs) Zone out 4x (un) Link Light Remark: Press and hold "I" (for a specific zone) or "ON" to switch to white mode. - Page 14 Cool-Spot in operation 7. Mi-light LED control > Linking & Unlinking LINKINg INSTRUCTIONS Power Power Turn off the light, wait 10 When the light is on, When pairing is complete, seconds, then turn it on briefly press one of the the light will slowly flash 3 again.
- Page 15 Cool-Spot in operation 8. Washing and Maintenance AIR SOCKS KE-Low Impulse® / KE-Interior® /KE-DireJet® Systems WASHING AND MAINTENANCE Wash Air Socks at 20-40°C with regular detergent for approximately 5-15 minutes at a time until the laundry Cool-Spot water is completely clean.
- Page 16 Cool-Spot BV Eemnesserweg 64 1271 LW Huizen The Netherlands T: +31(0)35 5244 137 www.cool-spot.nl...
