G-U SECURY Automatic Quick Start Manual

G-U SECURY Automatic Quick Start Manual

Door multi-point locking system secury automatic smart access controlled
Hide thumbs

Advertisement

Quick Links

Door Multi-point Locking System

Table of Contents

Edition 07.2020
03.5
SECURY Automatic
Smart Access Controlled
Wire & Connection
Diagrams
Information in this document can be modified without notice.
Quick Start Guide ...................................................................................03.5.3
Cable Duct ................................................................................................03.5.4
Wire Diagrams - Option 2
SECUREconnect 200 ...............................................................................03.5.5
Wire Diagrams - Option 3 - DOOR LEAF MOUNTED
SECUREconnect 200 & Code Keypad/Fingerprint Scanner ......03.5.6
Wire Diagrams - Option 4 - WALL MOUNTED
SECUREconnect 200 & Code Keypad/Fingerprint Scanner ...... 03.5.7
SECUREconnect 200 & Universal Module ......................................03.5.8
Wire Diagrams - Option 6 - DOOR FRAME MOUNTED
SECUREconnect 200 & Code Keypad/Fingerprint Scanner ......03.5.9
Cable Duct & Universal Module ....................................................... 03.5.10
Assembly and Operating Instructions ........................................... 03.5.11
Trouble Shooting .................................................................................. 03.5.16
03
5
03.5.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SECURY Automatic and is the answer not in the manual?

Questions and answers

Related Manuals for G-U SECURY Automatic

Summary of Contents for G-U SECURY Automatic

  • Page 1: Table Of Contents

    Door Multi-point Locking System Table of Contents 03.5 SECURY Automatic Smart Access Controlled Wire & Connection Diagrams Quick Start Guide ...................03.5.3 Wire Diagrams - Option 1 Cable Duct ....................03.5.4 Wire Diagrams - Option 2 SECUREconnect 200 ................03.5.5 Wire Diagrams - Option 3 – DOOR LEAF MOUNTED SECUREconnect 200 &...

  • Page 3: Quick Start Guide

    Door Multi-point Locking System І Automatic Smart Access Controlled Quick Start Guide Door manufacturer 1. Make sure you can manually open and close the door from the interior using either the profile cylinder knob, or interior operating handle before installing the access control system 2.

  • Page 4: Wire Diagrams - Option 1

    Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Wire Diagrams – Option 1 SECURY Automatic, A-opener, Cable Duct, 24V DC Solid brass handle & 45mm plate series Potential-free contact for external: DOOR FRAME - Intercom...

  • Page 5: Secureconnect 200

    Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Wire Diagrams – Option 2 SECURY Automatic, A-opener, SECUREconnect 200, 24V DC Solid brass handle & 45mm plate series Potential-free contact for external: DOOR FRAME - Intercom...

  • Page 6: Wire Diagrams - Option 3

    94 = Brown 95 = Green 96 = White Fingerprint scanner kit = K-C1440-01-0-0 GS = Yellow SECURY Automatic european profile cylinder lock Black = 90 Grey = GS Faceplate for SECUREconnect = 9-C4793-XX-0-8B Brown = VS (2 required) Potential-free contact...
  • Page 7 1.3A A-opener 110V AC, 60Hz Code keypad kit = K-C1440-73-0-0 Fingerprint scanner kit = K-C1440-61-0-0 SECURY Automatic european profile cylinder lock Black = 90 Grey = GS Faceplate for SECUREconnect = 9-C4793-XX-0-8B Brown = VS (2 required) Potential-free contact = by other...
  • Page 8 Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Wire Diagrams – Option 5 SECURY Automatic, A-opener, SECUREconnect 200, Universal Module, 24V DC Solid brass handle & 45mm plate series Smartphone with DOOR FRAME Danalock app.
  • Page 9 110V AC, 60Hz Code keypad kit = K-C1440-51-0-0 Fingerprint scanner kit = K-C1440-01-0-0 Cable relay -6 = B-55600-21-4-6 SECURY Automatic european profile cylinder lock Black = 90 Grey = GS Faceplate for SECUREconnect = 9-C4793-XX-0-8B Brown = VS (2 required) Potential-free contact...
  • Page 10 Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Wire Diagrams – Option 7 SECURY Automatic, A-opener, Cable Duct, Universal Module, 24V DC Solid brass handle & 45mm plate series Smartphone with DOOR FRAME Danalock app.
  • Page 11 Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Assembly and Operating Instructions GU-SECURY Automatic with A-opener – Technical Data Sheet Solid brass handle & 45mm plate series Assembly and Operating Instructions GU-SECURY Automatic with A-opener Technical Data Sheet ...
  • Page 12 A-opener, SECUREconnect 200 – Connection Diagram Solid brass handle & 45mm plate series     Connection diagram SECURY Automatic with A-opener (leaf-side)  Impulse-controlled door opening time approx. 2s (cannot be adjusted). Permanent door opening time corresponds to duration of control signal. ...
  • Page 13 Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Assembly and Operating Instructions A-opener, SECUREconnect 200, Fingerprint Scanner or Code Keypad Solid brass handle & 45mm plate series – Door Leaf Mounted Connection Diagram Cable routing of module (leaf-side) Please use the enclosed system cable to connect the module.
  • Page 14 Door Multi-point Locking System І Automatic Smart Access Controlled Door Multipoint Locking System Assembly and Operating Instructions A-opener, SECUREconnect 200R, Fingerprint Scanner or Code Keypad, Cable Relay -6 – Solid brass handle & 45mm plate series Door Frame Mounted Connection Diagram With the cable relay, the access control module can be mounted in the door frame.

  • Page 15: Assembly And Operating Instructions

    Door Multi-point Locking System І Automatic Smart Access Controlled Assembly and Operating Instructions A-opener, SECUREconnect 200, Fingerprint Scanner or Code Keypad, Relay-unit (white box) – Wall Mounted Connection Diagram Relay-unit (in white box) +24V SECUREconnect Edition 07.2020 03.5.15 Information in this document can be modified without notice.

  • Page 16: Trouble Shooting

    Door Multi-point Locking System І Automatic Smart Access Controlled Trouble Shooting Make sure you are using the right power supply: output 24V DC and min. 1.3A Any difference in voltage may cause malfunction and damage the system! Check wiring according to the correct option of wire diagram. Make sure no component is missing.
  • Page 17 Door Multi-point Locking System І Automatic Smart Access Controlled Trouble Shooting If using a SECURE connect 200, follow the steps below to perform a reset of the system: 1. Remove the plastic terminal block next to V4/93/92/91 on SC200R to reveal reset terminals 2.
