SETUP
Installation
Power Storage DC 8.0 / 10.0
This setup manual contains a short instruction required for
installing, wiring, commissioning and operating the inverters.
For further instructions on installing or operating, please refer
to the detailed user manual, which you can access via
www.rct-power.com.
RCT Power GmbH reserves the right to make changes to
specifications or documents without prior notice.
RCT Power GmbH shall not be responsible for any damages
resulting from use of this document.
This document does not replace any applicable laws,
regulations, standards or codes.
Warranty conditions come enclosed with the device.
warranties can be derived from this document.
Intended Product Usage
To prevent personal injury or property damage,
the inverter must only be installed, wired,
connected, commissioned, maintained and
serviced by qualified personnel:
•
Trained in installing electrical devices.
•
Familiar with all applicable laws, regulations, standards and
codes for electrical devices.
•
Familiar with safety requirements and safety-related
guidelines for electrical devices.
•
Familiar with work protection laws and regulations.
•
Using the appropriate personal protective equipment.
In 7 Steps to the installed system
Symbols
Explanation
Immediate danger
of death or serious
injury
Immediate danger
of minor or
moderate injury
Danger of
No
equipment or
property damage
Power Storage DC 8.0 and 10.0 are stationary 3-phase string
inverters with integrated battery charger. They convert direct
current (DC) supplied by the PV array and the battery into
alternating current (AC), which can be fed into the electricity
grid.
They are not designed for any other application or connection
to other devices.
Any use that differs from or goes beyond the intended usage is
considered misuse. RCT Power GmbH shall not be liable for any
damage resulting from misuse.
Any misuse will terminate warranty, guarantee and general
liability of the manufacturer.
Level of risk
high
medium
low
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RCT Power DC 8.0
Summary of Contents for RCT Power DC 8.0
- Page 1 Intended Product Usage Power Storage DC 8.0 and 10.0 are stationary 3-phase string To prevent personal injury or property damage, inverters with integrated battery charger. They convert direct the inverter must only be installed, wired,...
- Page 2 Assembly and mounting. (Section 2, p.3). Electrical connection of the devices. (PV, grid, battery section 3, p.4-5 / Communication section 4&5, p.7-8 and section 7, p-11 / Power Switch, Power Sensor section 6, p.9-10). Switch on Inverter (switch on fuses). (Section 8.1, p.12).
-
Page 3: Inverter Mounting
[1] Scope of Delivery Item Description Setup manual PV input- and battery connectors (Weidmüller PV-Stick) Wall bracket Inverter LCD display for information on inverter operation DC switch DC PV plugs Cable entries for communication ports Cable entry for AC cable Fig.1 Screw hole for additional protective grounding Name plate with technical data, serial number, symbols... -
Page 4: Electrical Connection
• Do not remove name plate. • Make sure other persons keep away during electrical work. • Only RCT Power certified batteries complying with the demands of the certain region are allowed to be used. [3.1] Overview Connection Parts Item Description AC terminal block for L1, L2, L3, N and PE phases. - Page 5 Step Description Remove cover of inverter. Locate AC terminal block (Fig. 2, A). Feed cable through AC entry (Fig. 1, e). Push down clamps to insert L1, L2, L3, N and PE. Tighten swivel nut of cable entry. [3.3] DC Connection Step Description Do not turn plug parts before inserting the cable.
- Page 6 Make sure the DC switch of the inverter is set to “0”, the battery ON/OFF switch set to “0” and AC through the main breaker or fuse is disconnected. Plug the battery connectors to the inverter. DC cable - DC cable + (The connection cables from the inverter to the battery is not included).
- Page 7 Step Description Use the feed cables for the corresponding cable entry (Fig. 1, d). Select correct port (see next section), press down spring clamp, insert cables and release. [4.2] Wiring of Communication Ports [5] RJ45 Connectors for Power Battery, Power Sensor and Power Switch communication The inverter communicates with the batteries via the CAN-Bus.
- Page 8 Standard communication with Power Battery Additional Power Switch communication Additional Power Sensor communication [6] Connection - Power Switch...
- Page 9 This Section applies only in use with a RCT Power Switch and battery system. Please note for a correct function of the Power Switch is only possible if the entire installation is as TN- C-S- or TN-S system! Step Description Switch off the system (show section 9).
- Page 10 The Power Storage DC system functionality depends on energy consumption measurement. This section applies only in use with a Power Sensor. Step Description Place the Power Sensor in the service entrance box. Click the three current sensors around the phases L1, L2 and L3 wires in the service entrance box.
- Page 11 If a storage system already exists this information can also be transmitted by networking via LAN / WLAN and thus dispenses with the RCT Power Sensor. Further configuration inter alia for the networking of RCT Power devices via LAN / WLAN can be found in the manual on our website www.rct-power.com.
- Page 12 Android APP. The Android APP is the central user interface for commissioning. It ensures easy data collection and troubleshooting. Obtaining Android App: Go to Google Play Store, search for “RCT Power App”, and install. Step Description Activate Wi-Fi on your smartphone (or tablet computer).
- Page 13 Start “RCT Power APP”. Switch to tab “Network” and press “Scan”. Activate “10.10.100.254“ (or if you have renamed the device choose this) by choosing radio button. If the connection is made with an inverter, the name is displayed on the head and the icon is edged.
- Page 14 Go to “Device” and click on “Settings”, then click “Battery”. Click on “Battery type” and select “Li-Ion RCT Power” or your corresponding battery type. Turn on the battery (or if available the batteries) by setting the battery /the batteries ON / OFF switch to “1”.
-
Page 15: Technical Data
The inverter now connects to the battery ( If 2 batteries are available the inverter first connects to one and then to the other). After the inverter checked the specifications and connected to the battery / the batteries, it starts to arrange the current sensor. -
Page 16: Battery-Input
Power Storage DC 10.0 Order Number IHP080N1AE0 IHP100N1AE0 DC-INPUT Max. recommended DC power 13200 W 16500 W MPPT 2 (paralleling possible) Input per MPPT Maximum DC current per MPPT 14 A ( 24 A in parallel mode) Rated DC voltage 700 V DC start up voltage / power 150 V / 40 W... -
Page 17: Block Diagram
PV – DC-switch Integrated DC overvoltage category AC overvoltage category Data interface WIFI, LAN, RS485, Multifunctional dry contact, 4 x digital in, 2 x digital in/out Display LCD dot matrix 128 x 64 with backlight Cooling Convection IP degree of protection IP 42 Max. - Page 18 RCT Power GmbH Line Eid Str. 1 78467 Konstanz, Deutschland Tel.: +49 (0)7531 996 77-0 Mail: info[at]rct-power.com Internet: www.rct-power.com 01/2021...
