SETUP
Installation
Power Storage AC 4.0 / 6.0
This setup manual contains a short instruction required
for installing, wiring, commissioning and operating the
inverters. For further instructions on installing or
operating, please refer to the detailed user manual,
which you can access via www.rct-power.com.
RCT Power GmbH reserves the right to make changes
to specifications or documents without prior notice.
RCT Power GmbH shall not be responsible for any
damages resulting from use of this document.
This document does not replace any applicable laws,
regulations, standards or codes.
Warranty conditions come enclosed with the device.
No warranties can be derived from this document.
Intended Product Usage
To prevent personal injury or property damage,
the inverter must only be installed, wired,
connected, commissioned, maintained and
serviced by qualified personnel:
Trained in installing electrical devices.
Familiar with all applicable laws, regulations, standards
and codes for electrical devices.
Familiar with safety requirements and safety-related
guidelines for electrical devices.
Familiar with work protection laws and regulations.
Using the appropriate personal protective equipment.
Symbol
Explanation
high
Immediate
danger of death
or serious injury
Immediate
danger of minor
or moderate
injury
Danger of
equipment or
property damage
Power Storage AC 4.0 and 6.0 are stationary 3-phase
string inverters with integrated battery charger. These
are used as a supplement to store surplus energy in
PV systems.
The stored energy of the battery is converted into grid-
compatible AC power and fed into the house network to
cover the household consumption.
They are not designed for any other application or
connection to other devices.
Any use that differs from or goes beyond the intended
usage is considered misuse. RCT Power GmbH shall
not be liable for any damage resulting from misuse
Any misuse will terminate warranty, guarantee and
general liability of the manufacturer.
EN
Level of risk
medium
low
