Installation & Operational Manual
Defender IM4-RFID
Lift Truck Impact Monitoring with RFID Card Reader Operator Access
Control with Automated Programmable OSHA Safety Check
RF Wireless
Integrated Visual Data Technology Inc. 3439 Whilabout Terrace, Oakville, Ontario, Canada L6L 0A7
IMPORTANT NOTE:
Please read first the ProxPoint Plus card
reader information on the end of this manual
referring to the programming method that is
required to get the system up and running.
RFID Proximity Card Reader
www.skidweigh.com
IM4-RFID M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM4-RFID and is the answer not in the manual?

Questions and answers

Related Manuals for IVDT IM4-RFID

Summary of Contents for IVDT IM4-RFID

  • Page 1 RFID Proximity Card Reader Installation & Operational Manual Defender IM4-RFID Lift Truck Impact Monitoring with RFID Card Reader Operator Access Control with Automated Programmable OSHA Safety Check RF Wireless IM4-RFID M Integrated Visual Data Technology Inc.

  • Page 2: Electromagnetic Compatibility

    General Installation Guide This IM4-RFID V1.25 Series installation & calibration guide describes how to install, set up, test and use your vehicle on- board impact monitor, RFID card reader operator access control with automated OSHA safety check. Following the instructions in the ADMINISTRATION MENU guide will enable you to get the system set up and operating quickly. In the event that you require additional assistance, please contact customer support via e-mail at support@skidweigh.com...

  • Page 3: Electrical Connections

    Note: Valid operator ID# card is required during system installation to enable vehicle operation (Verification of electrical connection of the BLUE and GREEN wires connected in series to one of the vehicle seat switch wire) and to be able to access the “Administration Menu”. Selecting the mounting location for digital indicator Use the mounting bracket with the anti vibration mount and fasten digital indicator on the vehicle dashboard, side railing on the right hand side or preferably on the overhead guard.
  • Page 4 For all SkidWeigh Plus Systems equipped with RFID card reader you MUST HAVE AT LEAST ONE VALID OPERATOR CARD in order to enable vehicle operation, program additional RFID cards and access the administration menu to set up and calibrate the system! IM4-RFID and SkidWeigh Plus series Keypad RFID Reader Toggle Arrows Keys in set up menu “Enter key”...

  • Page 5: Set Clock

    Use left ◀ and right ▶ arrow key (bottom left side of the keypad) to change from AUTO to MANUAL date/time set up. Note: AUTO set up refers to system utilizing a wireless RF platform with automatic date /time update from IVDT Base Station communication and programming hub.
  • Page 6 LCD Display Aug 28, 2010 12:20:23 “Enter key” ↵ Press to confirm the setting. The cursor will automatically move to the next item to be changed ( Month, Day, Year, Hours, Minutes, Seconds). On the last correction, seconds item press “Enter key” ↵ to confirm new date / time set up.

  • Page 7: Saving To Usb

    USB port USB Port Protective Cover Save data to USB The SkidWeigh Plus system will allow you to download all recorded data onto a USB Follow instructions shown on the LCD display drive. This function is located in Supervisor Menu to protect the integrity of the information.
  • Page 8 Set Up for LOW and HIGH Impacts Monitoring Press F key and than number 9 key and input password 521.
 Use left arrow keys to scroll through the menu to get to the SET IMPACT and follow the LCD instructions. Use left or right arrow for desired low impact value.
  • Page 9 Turn on ignition switch (Vehicle operation is disabled until valid RFID card is used) Scan valid operator RFID card LCD Display IVDT SCAN CARD LCD display will show date and time or LCD message prompts the operator to complete OSHA safety check procedure before vehicle operation is enabled.
  • Page 10 RFID Card Reader RFID MASTER CARD and one valid Each IM4-RFID system supplied to the end user includes one operator RFID card. The master card and one operator card is used to enable vehicle operation, access Administration menu for system set up, program additional operators RFID cards as required.
  • Page 11 Scan second valid HID operator card. Follow instructions shown on LCD display. Keep adding the valid cards to vehicle. When all cards inputed into the system press < KEY TO EXIT Lift Truck SkidWeigh RFID Authorized Operator Access System has a capability to add up to 150 valid operator cards.
  • Page 12 In the case of lost RFID operator card or master card, or reader malefaction in order to enable vehicle operation do a following: - With LCD Display showing “ IVDT SCAN CARD” press and hold F key for 5 seconds...
  • Page 13 ProxPoint Plus RFID Card Reader / SkidWeigh Technology Read Range Typical 3” Operating Voltage 12 to 55 VDC Operating Temperature (-35 C to 65C) Operating Humidity 5-95% non-condensing Transmit Frequency 125 kHz Card Compatibility All 125 kHz HID Proximity cards, long and short formats, as well as Corporate 1000 cards formats LED Type Bicolored (green and red) Transient Surge and Reverse Voltage Protection...
