Installation & Operational Manual
AC5-OS
Lift Truck RFID Card Reader Operator Access Control with
Programmable OSHA Safety Check
Integrated Visual Data Technology Inc. 3439 Whilabout Terrace, Oakville, Ontario, Canada L6L 0A7
IMPORTANT NOTE:
Please read first the ProxPoint Plus card
reader information on the end of this manual
referring to the programming method that is
required to get the system up and running.
RFID Proximity Card Reader
www.skidweigh.com
AC5-OS V1.25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC5-OS V1.25 Series and is the answer not in the manual?

Questions and answers

Related Manuals for IVDT AC5-OS V1.25 Series

Summary of Contents for IVDT AC5-OS V1.25 Series

  • Page 1 IMPORTANT NOTE: Please read first the ProxPoint Plus card reader information on the end of this manual referring to the programming method that is required to get the system up and running. RFID Proximity Card Reader Installation & Operational Manual AC5-OS Lift Truck RFID Card Reader Operator Access Control with Programmable OSHA Safety Check...

  • Page 2: Electromagnetic Compatibility

    General Installation Guide This AC5-OS V1.25 Series installation & calibration guide describes how to install, set up, test and use your vehicle on- board RFID card reader operator access control with automated OSHA safety check. Following the instructions in the ADMINISTRATION MENU guide will enable you to get the system set up and operating quickly.

  • Page 3: Electrical Connections

    Note: Valid operator ID# card is required during system installation to enable vehicle operation (Verification of electrical connection of the BLUE and GREEN wires connected in series to one of the vehicle seat switch wire) and to be able to access the “Administration Menu”. Selecting the mounting location for digital indicator Use the mounting bracket with the anti vibration mount and fasten digital indicator on the vehicle dashboard, side railing on the right hand side or preferably on the overhead guard.
  • Page 4 IMPORTANT For all SkidWeigh Plus Systems equipped with RFID card reader you MUST HAVE AT LEAST ONE VALID OPERATOR CARD in order to enable vehicle operation, program additional RFID cards and access the administration menu to set up and calibrate the system! Keypad RFID Reader Toggle Arrows Keys in set up menu...

  • Page 5: Set Clock

    Use left ◀ and right ▶ arrow key (bottom left side of the keypad) to change from AUTO to MANUAL date/time set up. Note: AUTO set up refers to system utilizing a wireless RF platform with automatic date /time update from IVDT Base Station communication and programming hub.
  • Page 6 LCD Display Aug 28, 2010 12:20:23 “Enter key” ↵ Press to confirm the setting. The cursor will automatically move to the next item to be changed ( Month, Day, Year, Hours, Minutes, Seconds). On the last correction, seconds item press “Enter key” ↵ to confirm new date / time set up.

  • Page 7: Saving To Usb

    USB port USB Port Protective Cover Save data to USB The SkidWeigh Plus system will allow you to download all recorded data onto a USB Follow instructions shown on the LCD display drive. This function is located in Supervisor Menu to protect the integrity of the information.
  • Page 8 Turn on ignition switch (Vehicle operation is disabled until valid RFID card is used) Scan valid operator RFID card LCD Display IVDT SCAN CARD LCD display will show date and time LCD message prompts the operator to complete OSHA safety check procedure before vehicle operation is enabled.
  • Page 9 General Each AC5-OS system supplied to the end user includes one RFID MASTER CARD and one valid operator RFID card. The master card and one operator card is used to enable vehicle operation, access Administration menu for system set up, program additional operators RFID cards as required. Note: Integrated Visual Data Technology Inc.
  • Page 10 The LCD display will indicate that “CARD ADDED OK “and short beep once LCD Display SCAN MORE CARDS < KEY TO EXIT Scan second valid HID operator card. Follow instructions shown on LCD display. Keep adding the valid cards to vehicle. When all cards inputed into the system press < KEY TO EXIT Lift Truck SkidWeigh RFID Authorized Operator Access System has a capability to add up to 150 valid operator cards.
  • Page 11 In the case of lost RFID operator card or master card, or reader malefaction in order to enable vehicle operation do a following: - With LCD Display showing “ IVDT SCAN CARD” press and hold F key for 5 seconds...
  • Page 12 ProxPoint Plus RFID Card Reader / SkidWeigh Technology Read Range Typical 3” Operating Voltage 12 to 55 VDC Operating Temperature (-35 C to 65C) Operating Humidity 5-95% non-condensing Transmit Frequency 125 kHz Card Compatibility All 125 kHz HID Proximity cards, long and short formats, as well as Corporate 1000 cards formats LED Type Bicolored (green and red) Transient Surge and Reverse Voltage Protection Extra Security, Recognizes card formats up to 85 bits with over 137 billion unique codes...
