VALZER NEXT
ISTRUZIONI D'USO
PER L'UTENTE
LEGGERE ATTENTAMENTE E CONSERVARE CON CURA
ASSIEME AL MOBILE
INSTRUCTIONS
POURL'UTILISATEUR
LIRE AVEC ATTENTION CE MANUEL ET LE
CONSERVERPRÈS DU MEUBLE AVEC SOIN
USER INSTRUCTIONS
READ CAREFULLY AND KEEP WITH THE CABINET
BETRIEBSANLEITUNGFÜR
BETREIBER
SORGFÄLTING LESEN UND MIT DEM MÖBEL
AUFBEWAHREN
INSTRUCCIONES DE USO PARA
EL USUARIO
LEER ATENTAMENTE Y CONSERVARCON ESMERO
JUNTO AL MUEBLE
INSTRUÇOES PARA O USO
LER COM ATENÇAO E GUARDAR COM CUIDADO JUNTO
AO MÓVEL
N° DOC. UM000169
REV. "A"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Costan VALZER NEXT
Summary of Contents for Costan VALZER NEXT
- Page 1 VALZER NEXT ISTRUZIONI D’USO PER L’UTENTE LEGGERE ATTENTAMENTE E CONSERVARE CON CURA ASSIEME AL MOBILE INSTRUCTIONS POURL’UTILISATEUR LIRE AVEC ATTENTION CE MANUEL ET LE CONSERVERPRÈS DU MEUBLE AVEC SOIN USER INSTRUCTIONS READ CAREFULLY AND KEEP WITH THE CABINET BETRIEBSANLEITUNGFÜR BETREIBER SORGFÄLTING LESEN UND MIT DEM MÖBEL...
-
Page 2: Safety Advice
AL FINE DI RIDURRE I RISCHI CONNESSI ALL’INFIAMMABILITA’, L’INSTALLAZIONE DI QUESTO APPA- RECCHIO NON DEVE ESSERE EFFETTUATA SE NON DA PERSONALE ADEGUATAMENTE QUALIFICA- OGNI ALTRO USO NON ESPLICITAMENTE INDICATO IN QUESTO MANUALE E’ DA CONSIDERARSI PERICOLOSO ED IL COSTRUTTORE NON PUO’ ESSERE RITENUTO RESPONSABILE PER EVENTUALI DANNI DERIVANTI DA USO IMPROPRIO, ERRONEO ED IRRAGIONEVOLE. -
Page 3: Avertissements De Sécurité
PROMISE CABINET PERFORMANCE. IN ORDER TO REDUCE FLAMMABILITY-RELATED RISKS, THIS CABINET MAY ONLY BE INSTALLED BY SUITABLY QUALIFIED PERSONNEL. ANY OTHER USE NOT EXPLICITLY MENTIONED IN THIS BOOKLET MUST BE CONSIDERED AS HAZAR- DOUS. THE MANUFACTURER DISCLAIMS ALL LIABILITY FOR DAMAGE RESULTING FROM IMPROPER, INCORRECT OR UNREASONABLE USE. - Page 4 INFORMATION ABOUT USE SAFETY WARNINGS FOR THE APPLIANCES USING R290 COOLING FLUID (PROPANE) Propane is a natural gas that doesn’t affect the environment but is inflammable. It is therefore essential to ensure that all refrigerant pipes are not damaged before connecting the appliance to the mains supply. Every 8 gr.
-
Page 5: Safety Information
SAFETY INFORMATION • Read the manual carefully and adhere to the contents before installing and using the appliance. • Always keep the instructions manual safe and if the appliance is sold, hand it over to the new owner. • This equipment is very dangerous if left exposed to rain, thunderstorms or bad weather with the power cable plugged into the power socket. -
Page 6: Handling And Unpacking
HANDLING AND UNPACKING The unit is shipped anchored onto a wooden base and protected by corner posts, cardboard top and nylon wrapping. Keep all packaging away from children. For each subsequent handling of the cabinet, the use of the wooden platform is recommended. Carefully remove the packaging, taking care not to damage the components and not to throw away those that will be needed for assembly. -
Page 7: Selecting The Place Of Installation
SELECTING THE PLACE OF INSTALLATION In selecting the place of installation, ensure that the following instructions are observed, this being vital for proper and troublefree working of the cabinet: • Do not install the cabinet outdoors. • Do not install the cabinet in the vicinity of heating radiators or other heat sources. •... -
Page 8: Installation
INSTALLATION To move the cabinet around on castor wheels, lift its feet. Take out packaging and clean all the cabinet using warm water together with 5% of neutral soap then dry it with a soft cloth; for the glass parts only use specific products, avoiding the use of water which can leave on the glasses limestone residues. - Page 9 CLIMATE CLASS ENVIRONMENT OPERATING TEMPERATURE 23,9 Warning! MAXIMUM ANGLE OF DOOR OPENING = 115° For correct working of the torsion bar and to avoid any break of the door or of the hinge do not exceed the maximum angle of door opening i.e. 115°. Stop the cabinet by feet.
- Page 10 LOADING INSTRUCTION WARNING: 1)The product must not obstruct the display area completely. 2)Avoid leaving shelves empty so as not to create turbulence wich may prejudic regular refrige-rated air flow, and cause needless energy consumption. TOP LOADING LIMIT INTERNAL SHELF LOADING LIMIT INTERNAL SHELF LOADING LIMIT INTERNAL SHELF LOADING LIMIT BOTTOM SHELF LOADING LIMIT...
-
Page 11: Putting Into Operation
PUTTING INTO OPERATION If the cabinet has been sharply tilted while being sited or for mounting of accessories, it must be left to stand for at least three hours before being started to allow the lubricating oil to settle in the compressor. Failure to do so can cause total destruction of the compressor refrigerating system. -
Page 12: Tank Cleaning
TANK CLEANING Unplug from the mains before cleaning. By tank cleaning, proceed as follows: 1) Place the goods in special refrigerated containers, kept at the same temperature and remove the shelves 2) Unplug the unit 3) Leave the doors open and begin the operation of tank washing when the tank temperature is the same as the ambient temperature. - Page 13 TEMPERATURE SETTING AND CONTROLS Each refrigerating appliance is provided with an electronic control for automatic maintenance of the appropriate pre-established temperature inside the tank. This temperature adjuster is gauged by the factory and should not be touched by the user. Only if the average internal temperature is too cold or not cold you can increment or decrement the temperature: - press the (Set) key in order to see on display the temperature set point.
- Page 14 INFORMATIONS ABOUT SERVICE MALFUNCTIONS AND REMEDIES Most of the functioning inconveniences are generally due to defective electrical connections. These problems can usually be solved on the place. The unit does not start: -check that there is voltage at the wall socket; -check that the unit is properly plugged.
- Page 15 REGOLAZIONE OBBLIGATORIA AD OGNI INSTALLAZIONE MANDATORY ADJUSTMENT AT EVERY SET-UP AJUSTEMENT OBLIGATOIRE POUR CHAQUE INSTALLATION EINSTELLUNG FÜR JEDE INSTALLATION ERFORDERLICH AJUSTE OBLIGATORIO CADA VEZ QUE SE INSTALE VERPLICHTE REGELING BIJ ELKE INSTALLATIE ✓ CORRECT • Dove sono presenti, regolare i piedini anteriori (utilizzando una pinza) per allineare le porte;...
- Page 16 -70-...
- Page 17 VALZER NEXT 1D Carico max ripiano ......49 kg Max weight on any shelf ....49 kg G.Vol. [L] N.Vol. [L] Poids max pour chaque tablette ...49 kg Höchstladen für jede Ablage ..49 kg Peso máx por estante ....49 kg Laad max voor jedere plaat ...49 kg...
- Page 18 -72-...
- Page 19 -73-...
