Contents WARNING ! 1-1 Stainless Waterproof Panel PC Assembly for SATA HDD Version..1-2 Installing for Mini PCI-e Card ............... 1-3 Installing for Mini PCI-e Card (Full Size) ..........Stainless 10.4" Waterproof Panel PC Exploded Drawing..................Stainless 15.1" Waterproof Panel PC Exploded Drawing.................. -
Page 3: Warning
WARNING ! 1. Please do not remove the caps of waterproof cables unless needed. 2. Waterproof cables must be fastened tightly on the connectors of system. 3. Waterproof cables must be examined by torque wrench, and the torgue must be more than or equal 5kgf-cm. 4. -
Page 4: Stainless Waterproof Panel Pc Assembly For Sata Hdd Version
1-1 Stainless Waterproof Panel PC Assembly for SATA HDD Version 1. Unscrew thirteen (M2.5*4) screws from the bottom cover and then lift the cover out of the system. (Fig.1) (Fig.1) (Fig.2) (Fig.3) 2. Fasten the HDD on HDD KIT with 3. - Page 5 (Fig.6) (Fig.7) 6. Connect the SATA DATA cable 7. Connect the SATA Power cable with motherboard. (Fig.6) with motherboard. (Fig.7) (Fig.8) 8. Screw the HDD KIT back to the system with four (M3*4) screws. (Fig.8)
-
Page 6: Installing For Mini Pci-E Card
1-2 Installing for Mini PCI-e Card (Fig.10) 45° (Fig.9) 9. Unscrew the(M2*6) screw from the screw 10. Install the mSATA into the connector thread on motherboard. (Fig.9) slot at a 45 degree angle. (Fig.10) (Fig.11) 11. Push the mSATA down to the motherboard Fasten mSATA with the (M2*6) screw. -
Page 7: Installing For Mini Pci-E Card (Full Size)
1-3 Installing for Mini PCI-e Card (Full Size) (Fig.13) (Fig.12) 12. Unscrew the(M2*6) screw from the screw 13. Install the mSATA into the connector thread on motherboard. (Fig.12) slot at a 45 degree angle. (Fig.13) (Fig.14) (Fig.15) 14. Push the mSATA down to the motherboard 15. -
Page 8: Stainless 10.4" Waterproof Panel Pc Exploded Drawing
Stainless 10.4" Waterproof Panel PC Exploded Drawing Name Q'ty Name Q'ty Waterproof Valve... -
Page 9: Stainless 15.1" Waterproof Panel Pc Exploded Drawing
Stainless 15.1" Waterproof Panel PC Exploded Drawing Name Q'ty Name Q'ty Waterproof Valve... -
Page 10: Stainless 19" Waterproof Panel Pc Exploded Drawing
Stainless 19" Waterproof Panel PC Exploded Drawing Name Q'ty Name Q'ty Waterproof Valve... -
Page 11: Ip (International Protection)
code- Levels of Protection (International Protection) IP XX First digit "X", Protection against solids. Protection against the contact of external solid bodies and the access to dangerous par Dimensions of the Description of test condition Image Level test material — No protection Protect against the access with any large surface of the body,... - Page 12 Second digit “X”, protection against liquids. Protection of the equipment inside the enclosure against harmful ingress of water. Protected Description of Description of Image Level against protection test condition — — No protection Dripping water . Test duration: 10 minutes Dripping water (vertically falling drops) .
- Page 13 Protected Description of Description of Image Level against protection test condition . Test duration: Water projected by a nozzle at least 3 minutes (6.3mm) against enclosure . Water volume: Water jets from any direction shall have 12.5 litres per minute no harmful effects.
-
Page 14: Introduction Of Necessary Tools
Introduction of necessary tools Adjustable ratcheting wrench (No. 21) Purpose If the waterproof connectors are damaged, oxidized or obsoleted, vse it to unfasten them. Torque wrench Purpose To examine if the torque of each waterproof connectors, are more than 5kgf-cm. Torque screwdriver Purpose To examine the torque of... -
Page 15: Packing List
Packing list M12 type cables will be varied by individual order shipment. l a i l i a fi cation 6G8006-2349-0100 DVD-R Z0028-0006 Screw Package S3*4 SIO NI*4 6G7800-3045-0100 Thermal Pad LF,30*45*5mm 6G3A64-3001-0000 STAR10.4",HDD Bracket, LF,SECC=1.0,Material 6G6003-1009-0100 SATA Power Cable LF,L=25cm,1*5/2.0 to 180°... -
Page 16: Difference Of Waterproof Cables
Difference of Waterproof cables 4 PIN POWER 8 PIN 12 PIN... -
Page 17: I/O Connector Pinouts
I/O Connector Pinouts LAN Connector PIN NO. Description PIN NO. Description TR0+ / TX+ TR0- / TX- TR1+ / RX+ TR1- / RX- TR2- / NC TR2+ / NC TR3+ / NC TR3- / NC VGA Connector PIN NO. Description PIN NO. - Page 18 USB Connector Description Description PIN NO. PIN NO. USB DATA - USB DATA - USB DATA + USB DATA + PW Connector PIN NO. Description DC-IN(12V) DC-IN(12V)
