Summary of Contents for Dateq SPL-EXT3
- Page 1 SPL-EXT3 Multi Color Display extension Manual SPL-EXT3_204101_V1.0EN...
- Page 2 Due to the nature of this product and it's designed functionalities it is considered to be used and installed solely by professional and certified installers and is not intended for consumer usage or resale. Consumer use is not supported by the manufacturer. SPL-EXT3_204101_V1.0EN...
-
Page 3: Safety Instructions..............................................3 Operation
DATEQ SPL-EXT3 Manual Safety instructions Safety instructions 1. All safety instructions, warnings and operating instructions must be read first. 2. All warnings on the equipment must be heeded. 3. The operating instructions must be followed. 4. Keep the operating instructions for future reference. - Page 4 Index Safety instructions..........3 Operation............8 Introduction............5 Technical specifications........10 Installation............6 Product support..........12 Connections...........7...
-
Page 5: Introduction........................................................5 Technical Specifications
DATEQ SPL-EXT3 Manual Introduction Introduction The SPL-EXT3 is a Multi color extension display that can be linked to the SPL-D3, SPL5 MK2 and SPL6 limiters. The display will show in green, orange or red the measured sound levels of the connected limiter. -
Page 6: Installation..........................................................6 Product Support
Installation DATEQ SPL-EXT3 manual Installation The SPL-EXT3 is installed apart from the audio source (a mixing desk for example), the speakers and amplifier. Image 1: Installing the SPL-EXT3 connected to the SPL5 MK2 Image 2: Installing the SPL-EXT3 connected to the SPL-D3 logger... -
Page 7: Connections
DATEQ SPL-EXT manual Installation Connections Jack 3-pens female Function Description SL Ground Data ground Tip Data TX Data send Ring Data RX Data receive Table 1: Display link connections Link This is the data connection with the optional SPL-D3, SPL-5MK2 or SPL6. For this a stereo 6.3mm jack cable is required. - Page 8 Operation DATEQ SPL-D3 manual Operation 1. Display 1: Shows the actual measured dB value in green, orange or red. 2. Filter weight: Shows the used filter weight in dBA, dBC or dB (no filter). 3. VU/Reduction bar: Shows the actual fast PPM level in dB.
- Page 9 8. VESA 50: Standard VESA 50 mount for wall mount, M4, max length 12mm. 9. Standard: Standard mounting bracket provided with the SPL-EXT3, M4, max length 12mm 10.Safety mount: M5 DIN screw for mounting an extra safety cable. Max screw length: 12mm...
- Page 10 Technical specifications Common Norm Measurement chain designed to comply according specifications IEC-61672-1 class 2 France: Measurement chain designed to comply according specifications NFS 31-122-1-2017 and decrét 2017-1244 Measurement chain designed to comply according specifications VLAREM-II Cat.1, Cat.2 and Cat.3 Measurement chain designed to comply according specifications DIN-61672, DIN-60651 and DIN15905-5 Link Optical isolated data protocol...
- Page 12 Product support For questions about the SPL series limiters, accessories or other products contact Dateq at: Dateq Audio Technologies B.V. De Paal 37 Phone: +31 (0)36 54 72 222 1351 JG Almere E-mail: info@dateq.nl The Netherlands Internet: www.dateq.nl...
