Ground Zero DSP Series Owner Manual & Specifications

Interface for wireless music streaming and app control
Owner´s manual & Specifications
With this interface connected to GZDSP 4-8X and XII units some of the functions can be controlled by
compatible smart devices with Android or iOS operating system. The necessary app can be downloaded
from the associated app stores. Apart from that, the interface allows wireless music streaming. Further
instructions on using the app can be found within the app manual of the connected unit. The operation is
available for turned-on GZDSP units, only.
Modell / model
Kompatibilität / compatibility
Audio Profil / audio profile
Audio Codec
BT Version
Sendefrequenz / transmission bandwidth
Max. Sendeleistung / transmission power (max)
Empfangsempfindlichkeit / receiving sensitivity (max)
Max. Reichweite / range (max)
Hauptprozessor / main MCU
*wenn dieser vom gekoppelten Gerät unterstützt wird / whenever supported by the paired device
Qualcomm aptX and CSR 8670 are products of Qualcomm Technologies Inc.
DSP SERIES
GZDSP BTS 4-8XII

Specifications

(AWV1.0)
GZDSP BTS 4-8XII
GZDSP 4-8X & GZDSP 4-8XII
A2DP 1.3.1 ( oder höher / or higher )
2.4 GHz Band / band (
Qualcomm CSR 8670 / BT class 2
SBC / aptX*
V4.2 compliant
2402–2480 MHz)
+ 10 dBm
- 90 dBm
10 m / 33 ft.
