ASSEMBLY
Step 1:
Remove the kite from the bag
and locate the Head Struts.
(diagram A)
Step 2:
Insert one Main Cross Strut into
Head Pockets A and B. Insert the
second Main Cross Strut into
Head Pockets C and D.
(diagram B)
Step 3:
Insert the Horizontal Head Strut
into Head Pockets E and F.
(diagram B)
Step 4:
Insert the Lower Head Strut into
the Head Pockets G and H.
(diagram B)
Step 5:
Tie the Spine, Cross Struts, and
Horizontal Cross Strut together
with the Center Webbing. Use a
simple bow knot Like tying your
shoe. (diagram B)
(Continued on next page)
A
B
Head Pocket C
Main Head
Cross Strut
Head
Pocket E
Head Pocket A
Head Pocket G
Bridle Loop
Center
Webbing
Spine Strut
(Pre-Installed)
Spine Sleeve
Lower Head Strut
assembly instructions
Main Head
Cross Strut
Horizontal Head Strut
Bridle Loop
Head Pocket H
Lower Head Strut
Horizontal Head Strut
Main Head Cross Struts
Head Pocket B
Head
Pocket F
Head Pocket D
