9636
RS-232C CABLE
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9636 and is the answer not in the manual?

Questions and answers

Related Manuals for Hioki 9636

Summary of Contents for Hioki 9636

  • Page 1 9636 RS-232C CABLE INSTRUCTION MANUAL...

  • Page 3: Table Of Contents

    Contents Introduction Shipping Check Safety Attentions During Use Chapter 1 RS-232C CABLE Overview 1.1 Overview 1.2 Printing Contents Chapter 2 Connection Procedure 2.1 Printer Model 2.2 Connection Procedure Chapter 3 3286 (-20) Settings 3.1 OPTION Mode 3.2 DATA OUTPUT SETUP Mode 3.3 Default Settings 3.4 Print Chapter 4 Troubleshooting...

  • Page 5: Shipping Check I

    If perchance you find any unclear portions, mistakes, omissions, or the like, we would be most obliged if you could please notify us of them via any HIOKI agent, or directly. Shipping Check When the product is delivered, check and make sure that it has not been damaged in transit.

  • Page 6: Safety

    ――――――――――――――――――――――――――― Safety DANGER Incorrect measurement procedures could result in injury or death, as well as damage to the equipment. Please read this manual carefully and be sure that you understand its contents before using the equipment. The manufacturer disclaims all responsibility for any accident or injury except that resulting due to defect in its product.
  • Page 7 ――――――――――――――――――――――――――― The following symbols are used in this Instruction Manual to indicate the relative importance of cautions and warnings. Indicates that incorrect operation presents possibility of injury to the user CAUTION or damage to the equipment. Denotes items of advice related to performance of the equipment or to its NOTE correct operation.

  • Page 8: Attentions During Use

    ――――――――――――――――――――――――――― Attentions During Use In order to ensure safe operation and to obtain maximum performance from the product, observe the cautions listed below. CAUTION To avoid electrocution, turn off the power to all devices before pluggingor unplugging any of the interface connectors.

  • Page 9: Chapter 1 Rs-232C Cable Overview

    Chapter 1 RS-232C CABLE Overview 1.1 Overview Measurement data can be output by connecting a printer with the RS-232C cable supplied with the 9636. To print from the 3286 (-20), press the HOLD for about one second to output the data.
  • Page 10 ――――――――――――――――――――――――――― 2. Printing Example 2 Current harmonics (Output format: ALL) Function Range Harmonic percentage Harmonics effective value Harmonic order 3. Printing Example 3 (Output format: DISP) Outputs the data displayed on the 3286 (-20) LCD. 1. 1φP 2. REC 3. BATT Lo ( The battery low is expressed.
  • Page 11 ――――――――――――――――――――――――――― 4. Explanation of the printing contents Function 1P_P : 1φP Meter 1P_PF: 1φPF Meter 3P_PF: 3φPF Meter HARM_I: Current harmonics HARM_U: Voltage harmonics Phase information -0.5deg: "-" means Lead phase. No sign means Lag phase. As for the setting of the output format, please refer NOTE to "3.2 DATA OUTPUT SETUP Mode".

  • Page 12: Chapter 2 Connection Procedure

    ――――――――――――――――――――――――――― Chapter 2 Connection Procedure 2.1 Printer Model Use our Model 9442 Printer and 1196 Recording Paper (both optional) Printer Model 9442 (Seiko Instrument Co., Ltd. Model DPU-414) AC Adapter for Printer 9443-02 (Seiko Instrument Co., Ltd. Model PW-4007- E1) (For the EU) 9443-03 (Seiko Instrument Co., Ltd.

  • Page 13: Connection Procedure

    ――――――――――――――――――――――――――― 2.2 Connection Procedure 1. Turn the 3286 (-20) and the printer off. 2. Connect the 9636 RS-232C cable to the DATA OUTPUT terminal of the 3286 (-20). Printer Connection Be careful of the cable direction when connecting it NOTE to the 3286 (-20).

  • Page 14: Chapter 3 3286 (-20) Settings

    To use an option with the 3286 (-20), enable its OPTION mode. 1. OPTION Types Input Model Name Function type 9636 RS-232C CABLE 9636-00 Printer Output 2. To activate the OPTION mode, hold the while pressing to turn the 3286 (-20) on. POWER 3.

  • Page 15: Data Output Setup Mode

    ――――――――――――――――――――――――――― is displayed, and the option setting reverts to its default. The digits may not flash, depending on the version NOTE of software used for the 3286 (-20). When using a version of software for which the digits do not flash, use the key to change the input type setting.
  • Page 16 ――――――――――――――――――――――――――― 5. When finished setting, turn the power off: (SAVE END) is displayed as the settings are saved. Display 2 Display 1 Display 3 Default Item Item No. Available Settings Value Name Items 2-04 and later are not displayed unless item NOTE 2-03 ( ) is set to...

  • Page 17: Default Settings

    ――――――――――――――――――――――――――― (4) RS-232C Communications Speed: Item 2-04 (BAUD) Select from 300/600/1200/2400/4800 or 9600 bps (5) RS-232C Data Length: Item 2-05 8 bits Set data length to 8 bits 7 bits Set data length to 7 bits (6) RS-232C Stop Bits: Item 2-06 1 bit Select one stop bit 2 bits...

  • Page 18: Print

    ――――――――――――――――――――――――――― Holding down the key, as turning power RANGE NOTE on, will display " " and initialize all the saved settings (RS-232C settings, SETUP function and measurement status saving function). 3.4 Print Enable both the OPTION mode and the DATA OUTPUT SETUP mode, then hold down the key for about one second to output the HOLD...

  • Page 19: Chapter 4 Troubleshooting

    ――――――――――――――――――――――――――― Chapter 4 Troubleshooting Although the following problems might seem to be program malfunctions, they can result from other causes. So before seeking repair service, please confirm the indicated items. Symptom Confirmation item not able to print it Confirm that the RS-232C cable is properly connected to the 3286 (-20).
  • Page 20 ――――――――――――――――――――――――――― ―――――――――――――――――――――――― Chapter 4 Troubleshooting...
  • Page 21 HIOKI 9636 RS-232C CABLE Instruction Manual Publication date: August 2002 Revised edition 3 Edited and published by HIOKI E.E. CORPORATION Technical Support Section All inquiries to Sales and Marketing International Department 81 Koizumi, Ueda, Nagano, 386-1192, Japan FAX: 0268-28-0568 TEL: 0268-28-0562 E-mail: os-com@hioki.co.jp...
  • Page 22 HEAD OFFICE 81 Koizumi, Ueda, Nagano 386-1192, Japan TEL +81-268-28-0562 / FAX +81-268-28-0568 E-mail: os-com@hioki.co.jp HIOKI USA CORPORATION 6 Corporate Drive, Cranbury, NJ 08512, USA TEL +1-609-409-9109 / FAX +1-609-409-9108 9636A980-03 02-08H Printed on recycled paper...
