- Page 1 Electric Lock User’s Manual Model: ET24 TOPENS Website www.topens.com VER 21a C030426...
- Page 2 Important Note: The open delay time of the 2 actuators must be set to more than 4S if the electric lock is used with dual swing gate opener which is powered by the DPS180-U AC-DC power supply, or the gate opener would work improperly. ...
- Page 3 Step 5: Connect the lock’s power cables to E-Plus board or the control board of TOPENS swing gate opener refers to the chapter “Wire Connection of the LOCK” . Note: Be sure that the clutch of the opener is engaged before you...
- Page 5 Step 5: Connect the lock’s power cables to E-Plus board or the control board of TOPENS swing gate opener refers to the chapter “Wire Connection of the LOCK”. Note: Be sure that the clutches of the openers are engaged before...
- Page 7 Wire Connection of the Lock 1. Wire Connection for A&AD&PW Series Swing Gate Opener The E-Plus board must be used with the E-Lock when it’s connected to the A&AD&PW swing gate opener. The E-Plus board is in the small box which is included in the package.
- Page 8 Wiring Diagram of the E-Lock to the AD&PW Series Swing Gate Opener...
- Page 9 2. Wire Connection of the Lock for KD 902 & AT1202 Series Swing Gate Opener The E-Plus board is not needed to use with the two gate openers. The electric lock can be wired to the “LOCK” terminal directly, no matter the polarity of the wires.
- Page 10 TOPENS Website www.topens.com Any question, please do not hesitate to contact us: E-mail: support@topens.com Kindly include your Product Model, Purchasing Date & Site, Order #, and your contact information. All your concerns will be replied within 24 hours. Tel: +86 (571) 8908 0213 (China)
