NuTone 710 Specification Sheet

MODELS 710,
714, 721 & 722
DESIGNER SERIES
FAN/LIGHT/NIGHT LIGHTS
Styled from the highest quality components to add a
dramatic touch to any bathroom
FEATURES
GRILLE:
• Corrosion-resistant, anodized aluminum grille (Polished brass
finish Model 710, Polished chrome finish Model 714)
• Solid oak frame (Models 721 and 722)
• Low profile
• Unique louver pattern - conceals interior
• Spring-mounted, moonstone glass light lens
• 100 Watt lamp capacity (bulb not included)
• Convenient 7 Watt night light (bulb not included)
BLOWER:
• Plug-in, permanently lubricated motor
• Centrifugal blower wheel
HOUSING:
• Rugged, 26-gage galvanized steel construction
• Adjustable mounting brackets span up to 24"
• Tapered, polymeric duct fitting with built-in backdraft damper
for easy, positive duct connection and no metallic clatter
NOTE: For installation in ceilings up to 12/12 pitch.
U.L. Listed for use in insulated ceilings (Type I.C.)
U.L. Listed for use over bathtubs and showers when connected to
a GFCI protected branch circuit (oak frames not recommended).
CONTROLS DESIGNED FOR USE WITH THESE PRODUCTS
(purchase separately):
Model 65V (Ivory), 65W (White): Fan/Light/Night Light Control with brass finish metal wall plate.
Model 66V (Ivory), 66W (White): Fan/Light/Night Light Control with plastic wall plate.
Model 67V (Ivory), 67W (White): Fan/Light/Night Light Control with chrome finish metal wall plate.
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
REFERENCE QTY.
TYPICAL SPECIFICATION
Fan/Light/Night Light unit shall be Broan Designer Series
Model 710 (714) (721) (722).
Unit shall have galvanized steel housing with adjustable
mounting brackets. It shall be ducted to a roof or wall cap.
Blower assembly shall be removable and have a centrifugal
blower wheel and permanently lubricated motor.
Ventilator to have 100 Watt maximum, incandescent lamp
with 7 Watt night light and glass lens. Grille shall be corrosion
resistant [with solid oak frame (Models 721, 722)].
Air delivery shall be no less than 100 CFM and sound level
no greater than 3.5 Sones. Air and sound ratings shall be
certified by HVI.
Unit shall be U.L.Listed for use over bathtubs and showers
when connected to a GFCI protected branch circuit.
Unit shall be U.L. Listed for use in insulated ceilings (Type
I.C.)
REMARKS
SPECIFICATION SHEET
HVI-2100 CERTIFIED RATINGS comply with
new testing technologies and procedures
prescribed by the Home Ventilating Institute,
for off-the-shelf products, as they are available
to consumers. Product performance is rated at
0.1 in. static pressure, based on tests conducted
in AMCA's state-of-the-art test laboratory.
Sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
50G
Date
99042920F
