NuTone AVD40KN Specifications

DESCRIPTION
•
24-guage steel cabinet
•
Heavy-duty ventilated metal board w/pad
•
Hot iron storage shelf
•
Utility/storage shelf
•
Door included (with Models AVD40WN & AVD40KN)
•
Door mounting - both left and right
•
Magnetic door catch
•
Board cover included
MODEL AVD40N
• Door sold separately
MODEL AVD40WN
•
Includes White MDF Door
MODEL AVD40KN
• Includes Simulated Oak Door
Additional Doors Available:
AVDORPN Oak Raised Panel - Unfinished
AVDWRPN Oak Raised Panel - White
AVDOFPN Birch Flat Panel - Unfinished
AVDMFPN Mirror Door - Beveled
Board
length - 42"
REFERENCE
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
QTY. REMARKS
Ironing Center
MODELS AVD40N, AVD40WN & AVD40KN
INSTALLATION
•
For built-in installation or optional surface mounting
•
Installation instructions included with each unit
ARCHITECT'S SPECIFICATION
Ironing center shall be NuTone PressRite
(AVD40WN) (AVD40KN).
Built-In Ironing Center shall be heavy gauge steel construction
in white finish. A 49¼"H x 14
Optional collar allows surface mounting when needed or desired.
Cabinet shall have ironing board safety retainer.
20B
Architectural & Engineering Specifications
Built-in
1 7
/ "W x 3 / "D wall opening is required.
8 8
Project
Location
Architect
Engineer
Contractor
Submitted by
February 2002
"Basic"
TM Model AVD40N
Date
99044000B
