EPS320B
CARDIAC STIMULATOR
QUICK INSTALLATION GUIDE
Micropace Document Part No. MP3156
Ver 1.8
Rx only
'henry'
or 4546
User Configuration Menu password:
'service'
or 9897
Service Configuration Menu password:
Check for latest Version of EPS320B Installation Manual at
http://www.micropaceep.com/
- Downloads
page
Applies to:
EPS320 Software V3.21 SR1, SR2+, V4.0
Two and Four Channel Stimulus Multiplexer Box
Touch Screen
Advertisement
Related Manuals for MicroPace EPS320B
Summary of Contents for MicroPace EPS320B
- Page 1 ‘henry’ or 4546 User Configuration Menu password: ‘service’ or 9897 Service Configuration Menu password: Check for latest Version of EPS320B Installation Manual at http://www.micropaceep.com/ - Downloads page Applies to: EPS320 Software V3.21 SR1, SR2+, V4.0 Two and Four Channel Stimulus Multiplexer Box...
- Page 2 EPS320B Cardiac Stimulator Quick Installation Guide for 4 channel Touch Screen Stimulator Unpack and verify all components are present as per Packing List. a. MP3113B-X (Touch screen) b. MP3102BT-X-X (SGU/Bona PC Carton and cable accessories) Stimulus Touch screen Generator SGU Power...
- Page 3 GE-EPS320B Combo Quick Install Guide NRTL Listed equipment approved by MET Registration Number E212294 Item Part No Description MP3008 Stimulus Generator Unit ( SGU ) MP3074 Power Supply GTM21089-1815-T2 ( PSU1 ) MP3109 BNC to Phone Signal Cable MP3033A Serial Boost RS232 Cable ( 2m )
- Page 4 EPS320B Cardiac Stimulator Lay out and connect Stimulus cabling, (under ground if required) between EPS320 Stimulus Generator Unit (SGU) and EP Amplifier (LS Pro and CardioLab recorders shown): LS Pro Amplifier LS Pro Amplifier CardioLab IEB CardioLab Amplifier Note: for CardioLab II, ECG output is found on the IEB Labelled “Anlg Out - 1”.
- Page 5 GE-EPS320B Combo Quick Install Guide Connect all power supplies to Isolation transformer and interconnect SGU and PC serial ports with MP3033A.
- Page 6 EPS320B Cardiac Stimulator Interconnect Eps320b Computer, LCD Display And SGU:...
- Page 7 GE-EPS320B Combo Quick Install Guide Now Set up the computer: a. Switch on (i) Isolation transformer, (ii) Bona PC (push front button once), (iii) LCD Display (on the side) and (iv) SGU at the rear. Allow system to boot up.
- Page 8 EPS320B Cardiac Stimulator Verify System (use checklist on last page): a. Verify Isolated Mains. Visually verify that all EPS320B components – PC, SGU, LCD Screen, are connected to a Medical Grade Mains Isolation Transformer e.g. MP3107. b. Clean launch. Verify that SGU and Software launch without errors.
- Page 9 GE-EPS320B Combo Quick Install Guide Train Customer a. Customize Stimulator settings. Sit down with the responsible customer – chief technician or physician and set up various defaults for the Stimulator – default S1 values in protocols, minimum S1 and Sx values in Configuration menu. Save defaults into one or more of the Setups.
- Page 10 EPS320B Cardiac Stimulator Troubleshooting 1. System problems Problem Explanation Suggested action No external ECG signal No External ECG 1. Select Alt-I, i.e. sense from catheter tip of connected to SGU ECG1 Input, paced electrode – this should always show an...
- Page 11 Ver 1.2, 1.6.06 , M.Cejnar Micropace Installation Checklist The following checklist is to be performed after installation EPS320B and before fist ‘live’ EP case. Any exceptions / failures must be signed off by Clinical specialist or engineer prior to use on patients.
