2. Bestimmungsgemäße Verwendung 3. Warnhinweise Bedienung 4. Aufbau 5. Verwendung in Kombination mit dem Symphonie Aqua System 6. Garantie Diese Bedienungsanleitung soll Ihnen den sicheren und bestmöglichen Umgang mit dem Gerät ermöglichen. Lesen Sie diese Anleitung vor der ersten Inbetriebnahme des Symphonie Aqua Lifters aufmerksam und vollständig durch.
1x Symphonie Aqua Lifter 2. Bestimmungsgemäße Verwendung Sehr geehrter Symphonie Aqua-Anwender, vielen Dank, dass Sie sich für den Symphonie Aqua Lifter entschieden haben. Dieser innovative Lifter wurde speziell für die Verwendung zusammen mit dem Symphonie Aqua VC TF System entwickelt. Umfangreiche Qualitätssicherung, Dokumentation, sowie engmaschige Tests zur Sicherstellung der fehlerfreien Fertigung unserer Artikel, sind grundlegend für Qualitätsprodukte der Firma...
3. Warnhinweise Benutzen Sie den Symphonie Aqua Lifter nicht wenn Sie eine Beschädigung am Gerät entdecken. Prüfen Sie vor jeder Benutzung den einwandfreien Zustand des gesamten Lifters. Versenden Sie den Symphonie Aqua Lifter nur in der Originalverpackung.
Es besteht eventuell Verletzungsgefahr durch scharfe Kanten am Lifter, bitte achten Sie beim Auspacken darauf. Der Symphonie Aqua Lifter wird komplett montiert geliefert. Sie müssen den Lifter lediglich aus der Verpackung entnehmen und einen geeigneten Standort in Ihrer Werkstatt wählen.
Page 6
Funktion 1: Sie können die Neigung der Ablageplatte des Lifters mit dem schwarzen Handrädchen nach Belieben verstellen. Funktion 2: Sie können die Höhe der Ablageplatte nach Belieben variieren. Dies Funktioniert folgendermaßen. Entnehmen Sie den Metallstab aus dem linken Halterfach. Verbinden Sie den Metallstab in die dafür vorgesehene Aussparung an der Pumpe auf der rechten Seite des Lifters.
Page 7
Hebel bleibt während des gesamten Gipsvorgangs auf der linken Seite! Wenn die gewünschte Höhe erreicht ist, können Sie mit dem Gipsvorgang beginnen. Nach Fertigstellung des Gipsvorgangs, können Sie den Symphonie Aqua VC TF Zylinder absenken. Hierfür stellen Sie den kleinen Hebel wieder auf die rechte Seite. Die Ablageplatte fährt von alleine nach Unten.
6. Garantie Wir gewähren auf den Symphonie Aqua Lifter die gesetzliche Garantie von 24 Monaten. In dieser Zeit gilt eine Garantie auf Materialfehler, vorzeitiger Verschleiß und Herstellungsfehler. Jegliche Modifikation am Lifter führt zum sofortigen Erlöschen der Garantie. Romedis GmbH behält sich, bezüglich der Produktgarantie, vor: ...
Page 9
Operating instructions Symphonie Aqua Lifter Romedis GmbH Georg-Wiesböck-Ring 5a 83115 Neubeuern Germany www.romedis.com As at 08/2019...
Page 10
9. Warning notice 10. CE conformity declaration Operation 11. Assembly 12. Usage in combination with the Symphonie Aqua System 13. Guarantee This operating manual is designed to provide you with the safest and best possible handling. Please read the instructions completely and attentively before initial operation and carefully store them for future accessibility.
8. Intended use Dear Symphonie Aqua User, Thank you for choosing the Symphonie Aqua Lifter. This innovative lifter was especially developed for use in combination with the Symphonie Aqua VC TF System. The quality products from the Romedis GmbH undergo extensive quality assurance and documentation, as well as close-meshed tests in order to ensure flawless production.
9. Warning notice Do not operate the Symphonie Aqua Lifter if damage to the device is discovered. Check that the lifter is in faultless condition before each use. Ship the Symphonie Aqua Lifter only in the original packaging.
There is a possible risk of injury due to sharp edges on the lifter. Please take care when unpacking the lifter. The Symphonie Aqua Lifter is already completely assembled upon delivery. You only need to remove it from the packaging and choose an appropriate location for it in your workshop.
Page 14
Function 1: You can set the desired tilt of the lifter platform by using the small, black handwheel. Function 2: You can vary the height of the platform, as desired. This works as follows: Remove the metal rod from the left holding pocket. Connect the metal rod to the intended recess on the pump, on the right side of the lifter.
Page 15
When the desired height is reached, you can begin with the casting process. After completion of the casting process, you can lower the Symphonie Aqua VC TF cylinder. For this purpose, place the small lever again on the right-hand side. The platform will slide down by itself.
12. Guarantee We grant a legal warranty of 24 months for the Symphonie Aqua Lifter. During this period, the guarantee covers material defects, premature wear and manufacturing defects. Any modification of the lifter results in immediate termination of the guarantee.
