Page 6
Sensor 传感器 Infrared receiver 红外线传接收器 Infrared receiver receiving signal from remote control 红外线传接收器接收来自遥控器的信号 Auto sleep when no movement in front of frame for around 10 min. Under auto sleep status, from will auto switch on when sense movement in from of frame. 在相框前面约10分钟无移动动作时, 相框自动休眠。...
Page 7
Remote Control 遙控器 Instruction guide of your remote control On / O Turn On/ O the wall frame 遙控器的使用说明 打开/关闭相框 Menu Go to menu 菜單 转到菜单 Enter Select / Play / Pause 確定 选择 / 播放 / 暂停 Left / Right Menu navigation / Video playback control 左...
Page 8
Set Up Your Picture Frame 设置您的相框 Kodak Wall Frame Please be prepared the following items before setting up 在安装之前请准备好以下事项 - Kodak Wall Frame - Remote Control - A smart phone - WiFi network which can access to the internet - Kodak 相框...
Set Up Your Wall Frame 设置您的相框 Kodak Wall Frame Kodak WiFi Kodak WiFi Select and con irm your WiFi network Then type in your password 确认您的网络 然后输入您的密码...
Page 10
Set Up Your Wall Frame 设置您的相框 Kodak Wall Frame If the password is correct, Select the iOS/ android QR code it will show as "Wi i Connected" on your Kodak Wall Frame to 如果密码正确, download the mobile app 它将显示 “已连接网络” 在 Kodak 云端相框上...
Download the Kodak Wall Frame App 下载Kodak Wall Frame 应用程式 Download and Install the Kodak Wall Frame App from Apple App store or Google Play 從Apple App Store或Google Play下载并安装Kodak Wall Frame App Open the application & sign up to create your account...
Register Your Account 注册您的帐户 Kodak APP Open the Kodak App through your phone Sign up a account by using a valid email address & setup your 通过手机打开 Kodak wall frame app username & password to login. Then click " Register"...
Page 13
Register Your Account 注册您的帐户 Kodak APP Registraction Success A veri ication mail will be sent to your provided email address. Then by clicking the activation link to complete the sign-up process 验证邮件将发送到您提供的电子邮件地址。 然后点击激活链接以完成注册过程...
Activate Your Account 启动您的帐户 Kodak APP Check your mailbox, click on the link 检查您的邮箱, 点击链结 Dear Customer, Thanks for your registration. Pls click on the link to activate your account, then log-in to enjoy the services. Thanks for using our products and services. 亲爱的客户, 感谢您的注册。 请点击连结以激活您的帐户, 然后登录以享受我们的服务。...
Page 15
Activate Your Account 启动您的帐户 Kodak APP Activation success Your account has been activate now. You can now login in. 激活成功 你的帐户已激活 现在可进行登入。...
Connect to Your Wall Frame 连接到您的相框 Kodak APP Click the “+” sign next to FRAMES or Scan QR code 掃描二維碼 press “Connect to New Frame” 点击 FRAMES 旁边的 “+” 符号 或 点击 “连接到新相框”...
Page 17
Connect to Your Wall Frame 连接到您的相框 Kodak Wall Frame Press “Enter” to show the Frame After the QR code scanning interface is opened, QR code,ready for scan Scan the QR code via your phone and start pairing 按 “确认” 键后, 会显示相框专属的...
Page 18
Connect to Your Wall Frame 连接到您的相框 Kodak Wall Frame Once your frame is connected to your phone, the Kodak logo will be appeared 当您的相框连接到手机时, 会出现Kodak商标 Now, customer can upload their picture and manage photos on the frame using mobile app 现在,...
Page 26
Kodak Wall Frame App - Assign playlists to the Frame 加入播放列表到相框 Kodak APP Step 1 Step 2 Step 3 步骤 1 步骤 2 步骤 3 Playlist Updated Select the frame Press on the playlist Select the playlist you want “Playlist Updated” will be show on 选择相框...
Page 27
Remote Control Functions 遥控器按钮功能 - 主页面 Kodak Wall Frame Video Photo To access your playlist page directly, press “Playlist” button 播放清单键: 直接进入播放清单页面...
Page 29
Remote Control Functions 遥控器按钮功能 - 主页面 Kodak Wall Frame Press “Enter” button to adjust the current image 按确定键对正在播放的相片作出调整 Rotate clockwise / anticlockwise Zoom in / out 顺时针 / 逆时针旋转 放大 / 缩小...
Page 30
Remote Control Functions - Display Menu Settings 遥控器按钮功能 - 主页面设置 Kodak Wall Frame Photo display duration adjustment 照片显示时长调整 Photo display mode adjustment (zoom in / zoom out / fade in & out / None) 照片显示模式调整 (放大/缩小/淡入/淡出/无) Photo transition mode adjustment ( it to screen / ill screen / full screen) 照片過渡模式調整...
Page 31
Display Menu Settings 主页面设置 Kodak Wall Frame Adjust the frame brightness level 自由调整亮度...
Page 32
Display Menu Settings 主页面设置 Kodak Wall Frame Play: ON/OFF to play video 播放: 开/关 播放视频 Time display: AMPM/24HRS/OFF 时间显示: AMPM/24小时制/关 Motion Sensor: ON/OFF 人体感应: 开/关 Change the photo display orientation: Horizontal/Vertical 更改显示方向: 水平/垂直...
Page 33
Display Menu Settings 主页面设置 Kodak Wall Frame Connect to WiFi 连接到WiFi Launcher information, include information on binded user ID, email, product serial number, launcher version, local storage information and “Check for Update” button 相框系统信息, 包括已绑定的用户ID, 电子邮箱, 产品序列号 , 相框系统版本, 本地存储信息, 检查更新按钮等...
Page 34
Kodak Wall Frame App - Edit/Upload Video 编辑/上传视频 Kodak APP Step 1 Step 2 Step 3 Step 4 Step 5 8 步骤 1 步骤 2 步骤 3 步骤 4 步骤 5-8 Select the local Video Select the video in which...
Page 35
Kodak Wall Frame App - Edit/Upload Video 編輯/上傳視頻 Kodak APP Step 1 4 Step 5 Step 6 Step 7 Step 8 步骤 1-4 步骤 5 步骤 6 步骤 7 步骤 8 Video is now ready for preview, Add tags for the video,...
Page 36
Kodak Wall Frame App - Others 应用程式 - 其他 Kodak APP Personal Pro ile Settings 个人资料设置 You are able to change your user pro ile password, language settings, and access to user application version for reference. Key Feature Settings :...
Page 37
Kodak Wall Frame App - Others 应用程式 - 其他 Kodak APP Step 1 Step 2 Step 3 步骤 1 步骤 2 步骤 3 Restore to factory settings 恢复设置: 恢复出厂参数设定 For reset to factory default: Select frame with online status then go to setting page and select sign out.
Page 38
Kodak Wall Frame App - Others 应用程式 - 其他 Kodak Wall Frame The frame reset to factory default User can set up the frame now (User guide page 4 for more details) 相框已经恢复为出厂设定 用户可以开始设置相框 (参考用户指南 page 4)
Page 40
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
