- Page 1 Start up Guide Series Balances Transcat.com | 800.828.1470...
- Page 2 1. CONTENT Models: TCT-125.C | TCT-225.C Weighing pan Draft shield Centering ring Bottom insert Power adapter Balance Models: TCT-164.C | TCT-224.C | TCT-314.C | TCT-524.C Balance Weighing pan Draft shield Bottom insert Power adapter Models: TCT-363.C | TCT-603.C | TCT-1003.C | TCT-3003.C Power adapter Balance Weighing pan...
- Page 3 2. WORKROOM AND BASIC OPERATION GUIDELINES Operate the device in a room where the temperature ranges +40 C between 10–40 °C (50–104 °F) and where the relative humidity is +104 F below 80%. +10 C Place the balance on a solid surface to ensure stability. To obtain stable and repeatable weighing results, an anti-vibration table is +50 F recommended.
-
Page 4: Remove Transport Lock
4. ACTIVITIES TO BE DONE PRIOR TO OPERATION 4.1. Remove transport lock Models: TCT-125.C | TCT-225.C | TCT-164.C | TCT-224.C | TCT-314.C | TCT-524.C Keep the transport lock should a warranty claim or service be required. Models: TCT-363.C | TCT-603.C | TCT-1003.C | TCT-3003.C | TCT-2102.C Keep the transport lock should a warranty claim or... -
Page 5: Components Assembly
5. COMPONENTS ASSEMBLY Models: TCT-125.C | TCT-225.C Models: TCT-164.C | TCT-224.C | TCT-314.C | TCT-524.C Models: TCT-363.C | TCT-603.C | TCT-1003.C | TCT-3003.C Install the grounding foot in a freely selected opening. Models: TCT-2102.C Install the grounding foot in a freely selected opening. -
Page 6: Preparing For Work
6. PREPARING FOR WORK 6.1. Balance temperature stabilization time Balance temperature stabilization Prior to switching the device on it is time ranges between 1 - 8 hours. necessary to ensure that it has reached a temperature equal to room temperature. E t h e U S B B U S 1... - Page 7 6.3. Leveling To level the precision balances, turn its feet and keep turning the feet until the air bubble in the rear of the balance takes the central position. The semi-micro and analytical balances feature a digital leveling system. Check the balance level state. The arrows Press leveling icon.
-
Page 8: Home Screen
7. PANEL AND SCREEN 7.1. Panel keys Proximity sensor Proximity sensor Switching ON / OFF Homescreen Confirming an Displaying previous operation or printing screen a report Taring Zeroing 7.2. Home screen List of current working Working modes list mode functions Status bar Weighing result window Editable information fields... -
Page 9: Basic Operations
8. BASIC OPERATIONS 8.1. Adjustment Press "Adjustment" button. Wait for the process completion. 8.2. Zeroing The balance has been zeroed. Unload the weighing pan and press "Zeroing" button. 8.3. Taring When the weighing result has been The balance has been tared. displayed press "Tare"... - Page 10 8.4. Working modes / units selection Press the pictogram to view list of all available working modes. Working modes list: Units list: Weighing Parts counting Dosing Animal Checkweighing weighing Formulas Solids density tola Press the pictogram to view Percent Liquids density list of all available units.
-
Page 11: User Settings
9.2. User settings Prior balance users setup, log in as the Administrator. Press "Databases" button. Select Operator database. Press "Add" button. Select "Name" parameter. Enter user name. User name has been entered. Following the above procedure, set remaining parameters: Code: Enter user ID Password: Enter user password... - Page 12 9.3. Proximity sensors setup Prior proximity sensors setup, log in as the Administrator. You can assign the proximity sensors with different functions for each working mode (the sensors will trigger different operation for each working mode). The diagram presents sensors setup for the weighing mode. Parameters list is displayed, select Press "Parameters"...
- Page 13 10. PERIPHERAL DEVICES CONNECTORS...
-
Page 14: Device Cleaning
11. DEVICE CLEANING 11.1. General Recommendations Prior to cleaning it is necessary to Use soft cloth made of either natural or Apply the cleaner onto the cloth. Mind disconnect the device from the mains. synthetic fiber exclusively. Avoid using not to apply the cleaner directly onto Remove the plug from the outlet, cloth made of stiff/hard fabric, this the device. - Page 15 11.3. Weighing chamber elements disassembly Prior to disassembling the weighing chamber, make sure the balance is turned off and unplugged form the mains. Press the moldings on the housing and lift the movable element up. Press the moldings on the Now you can remove the Now you can remove the front housing and lift the movable...
- Page 16 Remove the back glass. The Slide out the doors. housing has recesses to facilitate removing the glass. All disassembled elements are prepared to be cleaned. To reassemble draft shield, follow directions in reverse order.
