- Page 1 ThermCal400 Dry Block Temperature Calibrator INSTRUCTION MANUAL Please read all the information in this booklet before using the unit. August 2013...
- Page 2 The ThermCal400 Introduction The ThermCal400 calibrator provides a safe, dry, constant temperature source for checking and calibrating a wide range of temperature sensors, systems, indicators and thermometers It is fast and economical and can be used either on a bench top or as a portable field unit. The weight of the unit is only 11 pounds/five kilograms. The unit covers the temperature range from 5°C above ambient up to 400°C using a machined aluminum block as the...
-
Page 3: Specification
Specification Figures quoted are at the base of the well at the time of calibration. Temperature range: 5°C/9°F above ambient to 400°C/752°F Over-temperature limit: 450°C/842°F Display resolution: 0.1° Accuracy: ±0.25°C (30 to 200°C) ±0.4°C (200 to 400°C) Stability (after 20 minutes): ±0.020°C (50 to 200°C) ±0.040°C (200 to 400°C) Well to well radial uniformity:... -
Page 4: Working Environment
Working environment The calibrator units are designed to work safely under the following conditions: Ambient temperature range: 5°C/9°F to 40°C/104°F Humidity: Up to 95% relative humidity, non-condensing Warning Warning: HIGH TEMPERATURES ARE DANGEROUS Aviso: LAS TEMPERATURAS ELEVADAS SON PELI HIGH TEMPERATURES ARE DANGEROUS: They can cause serious burns to operators and ignite combustible material. -
Page 5: Installation
Installation 1. All Accurate Thermal Systems units are supplied with a power cable. 2. Before connecting the power supply, check the voltage against the rating plate. Connect the power cable to a suitable plug according to the table below. Note that the unit must be earth grounded to ensure proper electrical safety. -
Page 6: Operation
OPERATION Preparation The heater design, temperature sensor and control circuit give good temperature control and uniformity, but make sure that there is a close fit of the probes in the block to allow efficient heat transfer. Contact us about an insert that more closely fits your probe or device being calibrated. Plug the power cable into the socket in the back of the unit. - Page 7 Factory default control parameters The parameters used in the controller have been developed by Accurate Thermal Systems to give the best unit performance for most applications. If the need arises the “AT” autotune command can be run to further optimize results based on the thermal block load and ambient conditions.
-
Page 8: Operator Maintenance
Operator maintenance NOTE THAT THIS EQUIPMENT SHOULD ONLY BE DISMANTLED BY PROPERLY TRAINED PERSONNEL. REMOVING THE FRONT OR REAR PANELS EXPOSES POTENTIALLY LETHAL VOLTAGES. THERE ARE NO OPERATOR MAINTAINABLE PARTS WITHIN THE EQUIPMENT. In the unlikely event that you experience any problems with your unit which cannot easily be remedied, you should contact your supplier and return the unit if necessary. -
Page 9: Replacement Parts
Replacement Parts The following parts may be obtained from Anville Instruments Ltd. if replacements or alternatives are required: Part Number Description 4163 UK 240 volt power cable with 13amp UK plug (5 amp fuse) 4164 Euro style 240 volt power cable with R/A Schuko plug 4150 US style 120 volt power cable 4159... -
Page 10: Contact Information
Contact Information Accurate Thermal Systems LLC 61 Mohr Road Burlington, NJ 08016 Ph: 609-326-3190 Email: service@accuthermal.com Website: www.accuthermal.com GUARANTEE The unit is guaranteed against any defects in material or workmanship for the period of 3 years. This period is from the date of purchase, and within this period, all defective parts will be replaced free of charge provided that the defect is not the result of misuse, accident or negligence.
