User Manual
V21.01
Model: DGTEMPSCN
Description: 7 inch indoor wrist temperature scanner and hand sanitizer dispenser
Scan QR code to visit the product page:
Operating Instructions for Digital Signage
Note: Before using the product, please read the instructions carefully!
Do not attempt to disassemble this product. If the product does not work properly, please call
our Customer Service Department at 1-844-221-3393.
1 / 15
Advertisement
Table of Contents
Related Manuals for Displays2go DGTEMPSCN
Summary of Contents for Displays2go DGTEMPSCN
- Page 1 User Manual V21.01 Model: DGTEMPSCN Description: 7 inch indoor wrist temperature scanner and hand sanitizer dispenser Scan QR code to visit the product page: Operating Instructions for Digital Signage Note: Before using the product, please read the instructions carefully! Do not attempt to disassemble this product. If the product does not work properly, please call our Customer Service Department at 1-844-221-3393.
-
Page 2: Table Of Contents
Contents Features ..........................3 Safety Warnings and Precautions ................... 3 Assembly and Connection ...................... 5 Packing List ............................ 5 Interfaces ............................6 Steps for Assembly ........................6 Description of Basic Operation ....................7 Power on/off ..........................7 Launch Screen ..........................7 Screen displays after power ...................... -
Page 3: Features
4. Integrated hand sanitizer dispenser provides the essential cleansing solution to your guests and employees. Safety Warnings and Precautions Thank you for purchasing the wrist temperature scanner + hand sanitizer dispenser from Displays2go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. - Page 4 WARNING ⚫ Do not use power supply other than AC 110V, 60Hz. ⚫ Cut off the power supply before connecting or disconnecting any cables. ⚫ Do not place the device on any instable positions, or else it may be damaged or cause fire. ⚫...
-
Page 5: Assembly And Connection
CAUTION ⚫ Keep the small parts away from children to prevent them from swallowing. ⚫ If the device won’t be used for a long time, please turn it off and pull out the power plug. ⚫ To adjust the position of the device, please disconnect all power cords and move slowly to avoid tip over. -
Page 6: Interfaces
Interfaces 1. Power Cord Socket; 2. On/Off Switch; Note: Please pull out the power plug before installing or disassembling the unit! Steps for Assembly 1. Open the top cover as shown in Fig. 2; 2. As shown in Figure 3, the EPE is removed; 3. -
Page 7: Description Of Basic Operation
Description of Basic Operation Power on/ off Insert the power plug into the outlet. Press the ON/OFF switch to “I” to turn the unit on; Launch Screen Screen displays after power on 7 / 15... -
Page 8: Temperature Measuring Interface
Temperature measuring interface 1. When measuring the temperature, please measure the temperature within 3cm from the temperature sensor on the side, and align your wrist with the temperature sensor; 2. When body temperature is normal, it will be displayed in green with voice and text prompts, as shown in Figure 1;... -
Page 9: Parameter Setting Interface
Parameter setting interface "°C" is the Centigrade option; Temperature Unit: "°F" is the Fahrenheit option, and the following image interface is the Fahrenheit interface state; Screen brightness setting, minimum brightness: 1; maximum Screen Brightness: brightness: 10; Volume: Volume Setting Measurement Sensitivity: Sensor sensitivity setting Temperature Compensation (0.1): Temperature compensation setting... -
Page 10: Automatic Hand Sanitizer Dispenser
Automatic Hand Sanitizer Dispenser Open the front cover Use the key in the accessory bag. Insert into the keyhole on the top of the unit and slightly press downward to open the cover. See below: Part name 10 / 15... -
Page 11: Battery Installation
Battery installation Four 1.5V batteries, type C or No. 2, are required. NOTE: Batteries are not included. Refill hand sanitizer 1. The bottle in the container can be refilled. Gel Hand Sanitizer can be poured into the bottle directly. Before refill hand sanitizing liquid, make sure the nozzle is not at dispensing position. -
Page 12: Lndicator Status Prompt
Indicator status prompt 1. Green light flush every 5 seconds: working condition. 2. Red light flush every 5 seconds: battery is low, please change batteries. 3. Red light flush every 2 seconds: the sensor is blocked, please remove the object. 12 / 15... -
Page 13: Technical Specifications
Technical Specifications ITEM SPECIFICATION LCD size 7” Light source LED backlight Resolution 800*480 (pixels) Panel Refresh rate 60Hz Viewable area 154.1(H) mm * 85.9(V) mm Chromaticness 16.7M Voltage 100V~240V, 50-60Hz Power supply Power Consumption ≤20W Operating temperature (°C) 15~30°C Environment Operating humidity 85% RH Non-condensing Maximum operating time (hrs/day) -
Page 14: Troubleshooting
Troubleshooting the Device –DGTEMPSCN Issue Probable Cause Solutions ⚫ ➢ No display or sound Unit not plugged into wall outlet □ Check that the unit is plugged into wall ➢ Power cord not properly outlet. connected to the terminal on the □... -
Page 15: Names And Contents Of Toxic And Hazardous Substances Or Elements In The Product
Names and Contents of Toxic and Hazardous Substances or Elements in the Product Toxic and hazardous substances or elements Part name PBDE О О О О О Display О О О О × × Shell О О О О О Circuit board assembly * О...
