- Page 1 QCRND17PBK Item Name Image M4x10mm Screw M5 Nylon Lock Nut M5x16mm Screw Double Hole T-Slot Nut Single Hole T-Slot Nut M4 Washer M4x12mm Screw M6x30mm Screw M6 Serrated Lock Washer...
- Page 2 QCRND17PBK Hole for top of snap frame Top Acrylic Hole for bottom of snap frame Holes for T-slot mounting Holes for mounting Purell Dispenser Bent Acrylic...
- Page 3 QCRND17PBK Attach bent acrylic panel using 1x M4x10mm screw, M4 washer, and double hole T-slot nut as shown. Snap open the top and bottom rails of the snap frame to expose the mounting holes. Using the hole nearest the tab at the top of the...
- Page 4 QCRND17PBK Pivot the frame out of the way and install second double hole T-slot nut in the lower hole. Slide the assembly further down the T- slot and tighten all the screws as needed. Attach the top of the snap frame using the top slot on the top acrylic piece and the re- maining single hole T-slot nut.
