- Page 1 Instruction manual Model PS30SW Ⅱ DC Switching Power Supply...
- Page 2 Product Introduction PS30SW II Switching Power Supply is designed for radio amateurs. It is composed with a low ripple switching circuit which can perform like a linear power supply. It is small, light, portable, and efficient. Front panel 1. Power ON/OFF 2.
- Page 3 Rear panel Output terminal： Red connect ‘+’， Black connect ‘-’。 Current cannot exceed 30A Voltage fix/adjust knob ：At “13.8V” position, output fix at 13.8V. No. 4’s voltage adjust knob does not function。At “ADJUST” position，No. 4’s voltage adjust knob is 9-15V variable. Cooling fan 10.
- Page 4 1． Input voltage 220VAC ±10﹪ 50Hz Output voltage 13.8V or 9-15V variable Output voltage tolerance < 2﹪ Output current 25A continue，30A Max. Output ripple/noise < 80mVp-p Protection Overload, Short-circuit Fuse F5A250V Display indicator Display voltage or current Dimension 190（W）×70（H）×215（L）mm 10. Weight 2.3Kg Attention 1.
