- Page 1 ---- ---- FIREPLACES Installation Instructions Horizon Edge Natural Draft Electronic Ignition Gas Fireplaces 24/02/2021 24/08/2017 Ver. 5 Ver. 1...
-
Page 2: Before Installation
Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Installation Before Installation N.D.E.I system is supplied with all The Natural Draft Electronic Ignition (N.D.E.I.) flue required electrical fittings. Work needs to be system shall be installed by authorized personnel in accordance with the manufacturer’s installation undertaken by a licensed electrician if extending wiring. -
Page 3: Assembly Requirements
Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces ASSEMBLY REQUIREMENTS : EDGE MODEL SHOWN DOUBLE SKIN FLUE (SIZES VARY DUE TO MODEL ) 25mm CEILING CUTOUT GAP AROUND OUTER FLUE CEILING COMBUSTIBLE FRAMING IMPORTANT: BOTH CAPS NEEDS TO STAY OFF, IF HEAT ZONE IS NOT USED WALL LINING BY... - Page 4 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Measurement and Specifications FRONT OF FIREPLACE SECTION VIEW DETAIL Y - LIP TRIM ASSEMBLY ON/OFF SWITCH TO BURNER 3 PIN PLUG 240 VOLT 10 AMP ISOLATING SWITCH IMPORTANT: BOTH CAPS NEEDS TO STAY OFF, IF HEAT ZONE IS NOT USED REMOVABLE GAS...
-
Page 5: Framing Dimensions
Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces CEILING WITH 25MM AIR SPACE TO OUTER FLUE FRAMING DIMENSIONS Rear clearances to combustible material Edge: 25mm TWO SIDED WITH SIDE GLASS TWO SIDED 1100 EDGE 1307 1130 1500 EDGE 1683 1260 B* INCLUDING 10mm PLASTERBOARD IMPORTANT: VENTILATION INTO... - Page 6 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces HEAT ZONE CONVERSION CASING ACTIVE FLUE STANDARD VENT FULL WELD HOLES IMPORTANT: BOTH HEATZONE CAPS NEED TO STAY OFF, IF UNIT IS NOT VENTED INTO A ROOM SECTION A-A CEILING WITH 25MM FAN ( 300MM x 105MM ) AIR SPACE TO OUTER FLUE...
- Page 7 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces DRILL THROUGH THE BEAM , RAFTER OR FRAMING IF REQUIRED AND PUSH THROUGH THE THREADED ROD. THREADED ROD EYELET MAKE SURE THESE PLANES ARE PARALLEL, AND MAKE SURE ALL CORNERS ARE SQUARE •...
- Page 8 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces AUSTRALIAN APPROVED SECTIONS GAS COWL APPROVED FLASHING Run a bead of silicone down AUSTRALIAN APPROVED the vertical seam of the outer GAS COWL casing to the flashing CEILING WITH 25MM AIR SPACE TO OUTER FLUE,REQUIRED TO SEAL CHASE APPROVED...
- Page 9 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces HEAT ZONE CONVERSION CEILING IMPORTANT: IF HEATZONE KIT IS USED, UNUSED OUTLET MUST REMAIN UNCAPPED SW 2 SW 1 IMPORTANT: VENTILATION INTO CHASE FROM VENT 240MM X 90MM (SUPPLIED) 2 x10 amp GPO’S Fireplace ON/OFF Switch Optional Heat zone ON/OFF Switch General Purpose Outlet...
- Page 10 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces KEMLAN INDUSTRIES 13 FRENCH SERIAL No. xxxx AVENUE BRENDALE IAPMO No. GMK10737 QLD 4500 MODEL: MODEL NO. GAS TYPE BURNER GAS CONS. GAS CONS. INJECTOR INJECTOR T.P.P. T.P.P. HORIZON RANGE OPTION MJ / HR MJ / HR SIZE...
-
Page 11: Gas Installation
Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Laying the fire – Gas Installation Coal & Pebble Check unit is suitable for intended gas supply. Note position on gas appliance on drawing • Evenly spread a bag of Vermiculite into the burner specification on right hand side of appliance. - Page 12 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Laying the fire – Coal & Pebble MARK 2 COALS 700/800 – 600 X 155 MARK 2 PEBBLES 700/800 – 600 X 155 MARK 2 COALS 1000 – 992 X 135 MARK 2 PEBBLES 1000 –...
- Page 13 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Laying the fire - 850 Ceramic Log P O S I T I O N I N G O F A L L L O G S • It is important to follow the log recommended 2 .
- Page 14 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Laying the fire – 700 Ceramic Log P O S I T I O N I N G OF A L L L O G S • It is important to follow the log recommended positioning.
- Page 15 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Laying the fire - 700 Ceramic Log 4 . LOC ATE LOG NO. 4. 6 . L O C AT E L O G N O. 7 This log is placed with the thinner edge on the The charred effect of the log is positioned on the smaller coal.
-
Page 16: Commissioning Procedure
Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces User Instructions Commissioning Procedure 1. WARNING NOTE: Installed correctly the burner should not emit any Properly installed and fumes into the room. The following procedure should be operated this appliance will not leak gases. undertaken to test that the unit is operating correctly. - Page 17 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces TAIS 00-L140-D5-000V For further service information contact Kemlan Australia Head Office –13 French Avenue, Brendale, Queensland 4500 Telephone –PH: (07) 3490 5500 24/02/2021 Ver. 5...
- Page 18 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Service Instructions for Direct Ignition and Power Flue Horizon fireplaces. POWER FLUE SERVICE INSTRUCTIONS PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION PILOT WILL NOT LIGHT WITH FAN - CHECK FOR GAS SUPPLY AND TURN ON...
- Page 19 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces DIRECT IGNITION PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION - CHECK FOR GAS SUPPLY AND TURN ON ALL CONNECTIONS PILOT WILL NOT LIGHT 1) NO GAS - CHECK GAS PRESSURE - CHECK PILOT AND CLEAN INJECTOR - CHECK ELECTRIC SUPPLY AND TURN ON ALL SWITCHES - CHECK ALL CONNECTIONS...
- Page 20 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Trouble shooting guide for Techrite ignition pack Warning: This is a 240VAC module. All connections to the module are 240V (except ignition cable and flame sense). Ensure power is switched off before checking any connection or replacing any components.
- Page 21 Installation Instructions Kemlan Natural Draft Horizon Edge Gas Fireplaces Flash Code Meaning Possible Cause (Red LED) Pressure switch fail Check combustion fan. Check unit has started and pressure switch and connections. during heat cycle the Check flue for obstructions pressure switch has opened Notes: The ignition unit is polarity sensitive.
-
Page 22: This Warranty Does Not Cover
WARRANTY FOR HORIZON MODELS Provided the appliance has been correctly installed according to instructions, Kemlan guarantee the cost of replacing parts and the labour in connection therewith for a period of 12 months from the date of installation. THIS WARRANTY DOES NOT COVER – Failure to comply with manufacturer’s operation instructions.
