North Avenue Collection | Model 420043
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-445-1527.
Share your journey!
Get your gear a
mobile home.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-13
Français pg 14-15
Español pg 16-17
Lot #: 517697
Date Purchased: __________________
05/16/18
Be sure to give us a ring before
making any returns. 1-800-445-1527

Advertisement

loading
Need help?

Need help?

Do you have a question about the North Avenue 420043 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sauder North Avenue 420043

  • Page 1 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. FUTURE REFERENCE. Prefer the phone? Call 1-800-445-1527. English pg 1-13 Français pg 14-15 Español pg 16-17...
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-13 Hammer Not actual size Français 14-15 Español 16-17 Skip the power trip. Safety This time. Warranty Page 2 www.sauder.com 420043...
  • Page 3 While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. SHELF (2) RAIL (3) UPPER FRONT RAIL (1) END (2) BRACE (2) 420043 www.sauder.com Page 3...
  • Page 4 Screws are shown actual size. You may receive extra hardware with your unit. CAM SCREW - 20 HIDDEN CAM - 20 ALLEN WRENCH - 1 HEX WRENCH - 1 CASTER - 4 1/2" ALLEN SCREW - 8 1-7/8" ALLEN SCREW - 8 1-3/16" ALLEN SCREW - 4 Page 4 www.sauder.com 420043...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Turn twenty CAM SCREWS (1) into the RAILS (G), UPPER å...
  • Page 6 Step 2 Push eight WOOD DOWELS into the edges of a SHELF (F). å Be sure to use the exact holes shown. Repeat this step for the other SHELF (F). å Page 6 www.sauder.com 420043...
  • Page 7 RAILS. point toward the edge of the board. Arrow The arrow must point (6 used) toward the edge of the board and CAM SCREW. Curved edge The CAM SCREW is closer to this edge. 420043 www.sauder.com Page 7...
  • Page 8 The CAM SCREW is closer to this edge. The arrow must point toward the edge of the board and CAM SCREW. (6 used) The CAM SCREW is closer to this edge. Page 8 www.sauder.com 420043...
  • Page 9 Fasten the BRACES (J) to the SHELVES (F). Use four å 1-3/16" ALLEN SCREWS (11) and the ALLEN WRENCH (5). Now might be a good time to refresh your drink. 1-3/16" ALLEN SCREW (4 used in this step) (4 used) 420043 www.sauder.com Page 9...
  • Page 10 The arrow must point toward the edge of the board and CAM SCREW. The arrow must point 1/2" ALLEN SCREW toward the edge of the (4 used for the BRACES) board and CAM SCREW. (4 used) Page 10 www.sauder.com 420043...
  • Page 11 The arrow must point toward the edge of the board and CAM SCREW. The arrow must point toward the edge of the board and CAM SCREW. 1/2" ALLEN SCREW (4 used) (4 used for the BRACES) 420043 www.sauder.com Page 11...
  • Page 12 Step 8 Fasten the CASTERS (4) to the ENDS (I) with the HEX å WRENCH (6). Turn the hex nut on the CASTER until it is tight. Hey! It's starting to look like something! Page 12 www.sauder.com 420043...
  • Page 13 NOTE: Please read the back pages of the instruction å booklet for important safety information. This completes assembly. Clean with your favorite å furniture polish or a damp cloth. Wipe dry. And to celebrate, why not share your success story? 25 lbs. 35 lbs. 420043 www.sauder.com Page 13...
  • Page 14 élément et conserver le livret pour future référence. TABLETTE .................2 VIS D'EXCENTRIQUE ...........20 Pour contacter Sauder TRAVERSE ................3 EXCENTRIQUE ESCAMOTABLE ....18 en ce qui concerne cet TRAVERSE AVANT SUPÉRIEURE ....1 CHEVILLE EN BOIS ..........16 élément, faire référence...
  • Page 15 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer 420043 www.sauder.com Page 15...
  • Page 16 ESTANTE ..................2 BIELA DE EXCÉNTRICO ..........20 et conserver le livret pour future référence. RIEL ....................3 EXCÉNTRICO ESCONDIDO ........18 Pour contacter Sauder RIEL DELANTERO SUPERIOR ........1 PASADOR DE MADERA ..........16 en ce qui concerne cet EXTREMO ..................2 RUEDECITA .................4 élément, faire référence...
  • Page 17 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. 420043 www.sauder.com Page 17...
  • Page 18 Además, el un televisor. soportar un televisor. peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 18 www.sauder.com 420043...
  • Page 19 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 20 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
