PRODUCT INSTALLATION

Power supply

DMX connection

Operating instructions
3
2
ENTER
ESC
LASER
STATUS
4 LOCK
DMX
SAFETY EYE OUTPUT
ATTACH SAFETY
CABLE HERE
DMX
INPUT
5
FONCTION
1 LASER output
2 Keyboard
3 Microphone
4 LED status
5 Secutrity hook
6 Power connector
7 DMX connectors
8 Bracket screw
9 Display
10 INTERLOCK connector
11 Security key
9
2
11
MIC
10
REMOTE
INTERLOCK
7
S P E C T R U M 8 0 G R E E N
POWER
6
8
DESCRIPTION
Laser Beam output
For menu/function selection
Audio detection
STATUS LED , light ON when Laser beam is active
Attach safety cable here
Mains connectors
DMX IN and DMX OUT
Adjust projector position
Menu/function display
For security shutdown of laserbeam EN 60825-1:2014
For security shutdown of laserbeam EN 60825-1:2014
