Posnet TEMO ONLINE Quick Start Manual

Manual installation of controllers

Installation of printer's controllers ends with establishing a virtual COM
port to facilitate communication with a computer via USB. This is an
automatic process upon connecting the printer to a computer.
Installation can start by clicking with the right mouse key on the
controller's file featuring INF extension, and next selecting Install from
the menu.
Controllers are on a CD (it should be in the box with the printer) and the
most up-to-date version can be downloaded from the posnet.com
website.

Exchanging paper

1
Press the open button so that the lid pops up.
2
Place the roll in the paper chamber. Paper's end should be placed
so that a couple of centimeters extends beyond the stalk.
3
Close the printer's lid.
2
1

Setting communication interface

Using [UP] / [DOWN] keys select from printer's menu:
1
„2 Konfiguracja"
„1 Interfejs PC", where each item should be confirmed with [OK].
Next, using the same keys select an interface (USB, COM1,
2
COM2, TCP/IP).
If the POSNET protocol was selected specify standard of Polish
3
characters (Windows 1250, Latin 2 or Mazovia).
Confirm with [OK].
4
The printer will restart.
This manual describes basic printer elements, installation of
standard controllers and connecting the printer to a computer.
Description of installation and configuration of controllers
(USB(NET)) for online connections has been described in the
Quick OnLine instruction attached to the package.
3

The printer can be optionally fitted in a WiFi / Bluetooth adapter.

POSNET POLSKA S.A., as the manufacturer, hereby declares that
the WiFi/BT TEMO device is conform with provisions of 2014/53/EU
Directive.
Full text of the EU conformity declaration is available at:
http://www.posnet.com.
Full version of the manual is available at www.posnet.com.
„2 Konfig. połączeń" „1 Usługi PC"
Document version 1.3
