- Page 1 Sun Ray RF Control Pack Installation Instructions Type 1: Gateway Type 2: Power Monitor Installation and operating manual...
-
Page 2: Table Of Contents
Index Introduction.......... 3 Preliminary considerations ......4 Tevolve System Elements ......5 Installation instructions ......6 Gateway ..............6 Power Monitor .............. 7 Registering the Gateway in the web portal ......9 Pairing ..............10 Technical characteristics ......13 Gateway ..............13 Power Monitor ............ -
Page 3: Introduction
Introduction Introduction Congratulations on acquiring the ATC SunRay RF Control Pack. With it you will be able to control and program the temperature of your home and know your total electricity consumption at any time. Also, you will be able to carry out all these... -
Page 4: Preliminary Considerations
Preliminary considerations Preliminary considerations Disconnect the mains power in your home before installing the electrical Power Meter. It must be possible to isolate the electric power supply circuit of the electric Power Monitor by a 2 pole switch where the distance between contacts must be a minimum of 3mm. -
Page 5: Tevolve System Elements
Sold Separately, Requires the Sun Ray RF Gateway to function. SunRay RF Control System is distributed in different packs with some or all of the devices. Follow the instructions for installing the elements... -
Page 6: Installation Instructions
Installation instructions Installation instructions Gateway Connect the gateway to the router using the Ethernet cable orange green Connect the USB cable to the ethernet Gateway and the power supply supplied. micro USB Wait two minutes and use the Gateway LED lights to check that Status of Gateway lights it is communicating correctly with the router. -
Page 7: Power Monitor
Installation instructions Requirements for correct operation • To operate correctly the Gateway needs an Internet connection via a broadband router. The equipment can operate with broadband networks, cables and others, and in most cases, no set up in the router is necessary. • If there are any connection problems or if operating in a corporate network, check with an IT technician that the following requirements are met. - Page 8 Installation instructions Connect the power supply cable to the terminals L and N of the Power Monitor. Remember to disconnect the power supply from the circuit breaker where the Power Monitor will be connected. Place the Power Monitor in the DIN rail on your control panel where there is available space.
-
Page 9: Registering The Gateway In The Web Portal
Installation instructions Registering the Gateway in the web portal Once all the system components you have are installed, access the web portal at the following url: https://tevolve.termoweb.net and select create a new account. Fill in the fields indicated in the form: User: enter your e-mail address. Password: enter a password for accessing the system and confirm it in the following field. -
Page 10: Pairing
Installation instructions Pairing Gateway Once Gateway connected to the Internet and orange registered in the web portal, green the devices must be paired to it. To do this, put the Gateway in discovery status press the Link button for 3 seconds. The orange LED starts to flash. - Page 11 Installation instructions Sun Ray RF electrical radiator To pair the radiator, when Gateway is in pairing mode, press the OK key for 3 seconds until the symbol appears in the top right of the thermostat screen. Wed. 11:00 Set point: .5°C COMFORT 3sec.
-
Page 13: Technical Characteristics
Technical characteristics Gateway • Desktop or wall placement • Power supply: 5V 500mA micro USB external current adapter. • Dimensions: 80x80x22mm • RJ45 connector for Ethernet connections • Communication frequency: 869Mhz • Operating temperature 0 ºC to 60 ºC • Storage temperature -20 ºC to 85 ºC Power Meter • DIN rail placement. - Page 14 Notes about installation...
- Page 15 Notes about installation...
- Page 16 Date of Purchase. Any unauthorised repair or attempted repair will invalidate the Guarantee. You may be asked to return the product to atc for inspection to establish whether the fault is covered under the Guarantee. The Guarantee is valid in the UK and Ireland only.
