Page 3
27736 Mobile 40 Tub Storage Cart Part Drawing Description Ctn. Part Drawing Description Ctn. Qty Hardware List Phil Screw M6X15mm 16 EA Left Leg Welded 1 EA CS Phil Screw M6X50mm 18 EA Wood Screw M7x50mm 7 EA Right Leg Welded...
Page 4
¼” Phil Head Lock Screw 2 EA 4 EA Allen Wrench 1 EA Small Tube Closure 4 EA Large Tube Closure 4 EA NOTE: 27736 Mobile 40 Tub Storage Cart comes in two boxes 58468 Box 1 58469 Box 2...
Assembly Diagram To Assemble: Illustration # 1 Identify and Separate all the Parts and Hardware. Install 2 each Cam Posts (C2) in the 2 threaded insert nuts in the Top Panel (P5) as shown in illustration #1. Install 1 Wood Dowel (G) in the hole in the middle of the Be sure that arrow on top of Camlock (C1)
Page 6
Attach Middle Panel (P4) to the Top Panel Illustration # 3 (P5) as shown in illustration #3. Secure by turning the Cam Locks (C1) 1/4 Turn until they lock. Attach Bottom Panel (P6) to the Middle Panel (P-4) using 2 Wood Screws (A2). To Secure Cam Locks, Insert Large Phillips Head Screwdriver and...
Page 7
Illustration # 5 Slide 9 Shelves (P8) over Middle Panel (P4) and into slots in Slotted End Panel (P3) as shown in illustration #5. Place Slotted End Panel (P3) over the end of 9 Shelves (P8) as shown in illustration #6. Attach Left Leg Welded (P1) to the Top and bottom Panels (P5 &...
Page 8
Place the Left Door (P9) with the Predrilled (for Hinges) holes facing up and Insert 1 each Lock Cylinder (K1) through the hole in the Left Door (P9) as shown in illustration # 7. Secure Lock Cylinder (K1) using the Lock Washer (K2) and the Lock Hex (K3). INGER IGHTEN Slide Lock Retainer (K4) over the square end of Lock Cylinder (K1).
Page 9
19. Attach Back Panel (P7) to the Left Leg Welded (P1), and the Right Leg Welded (P2) using 6 screws (A1) as shown in illustration #9. Secure Back Panel (P7) to the Middle Panel (P4) and the Bottom Panel (P6) using 4 Screws (A2).
Page 10
Attach Left Door (P9) to Illustration # 11 Left Leg welded (P1) using 6 screw (A3) as shown in illustration #11 and Detail #11A. Attach Lock Catch (J) to Detail # 11A Middle Panel (P4) using 2 screw (A5) . See Detail #15A.
Page 11
27. Attach Magnet (H) on the back at the top of each Leg Weld assembly using two Screws (A5) and into the punched holes. Attach a Metal Plate (I) to the front of each Door using a CS Screw (A7) as shown in illustration #13. Illustration # 13...
Page 12
27736 Mobile 40 Tub Storage Cart 19 1/4” 45 1/4” 49 1/2” 56 1/2” 22 1/2” Tub Space 21 1/4” W X 14 3/4” D X 4 1/2” T 27736_02-29-16 WWW.MYBINDING.COM...
