  • Page 1 ANGE PICO MICRO LITE User Manual V1.0 www.silvernet.com...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Introduction ..........................4 Supported Products ....................... 4 Wireless Modes ........................4 System Requirements ......................4 Packing list ..........................5 The Enclosure and LED indicators ....................6 Configuration ..........................7 Getting Started ........................7 Navigation ..........................8 Status ............................9 Overview ..........................
  • Page 3 Radio frequency Interference Requirements ............... 49 Troubleshooting ........................51 Warranty ..........................51 Contact SilverNet ........................51 Copyright Information ......................51 Other SilverNet Products ......................52 Pro Range ..........................52 Industrial Network Transmission ..................52 Intelligent Wi-Fi Solutions ....................52 Industry Leading Technical Support ..................52...

  • Page 4: Introduction

    NTRODUCTION This User Guide describes the firmware version 2.0.9 which is integrated into all Pro Range products provided by SilverNet Ltd. UPPORTED RODUCTS This manual covers all GEN4 products listed below: • PICO • MICRO • LITE • MAX For more information, visit www.silvernet.com...

  • Page 5: Packing List

    ACKING LIST Please check the following items in the package before installing the device Wireless Radio 1 piece User manual 1 copy Cable Gland 1 piece Mounting bracket 1 piece Power over Ethernet Injector 1 piece Power cable 1 piece Set of screws 1 piece Please contact your distributor immediately for any missing or damaged items.

  • Page 6: The Enclosure And Led Indicators

    NCLOSURE AND INDICATORS Mark Name Function Press to reboot the device manually Reset Button Hold to rest the device to factory settings Ethernet Port (PoE) 10/100Mbps Ethernet port and PoE power input (48V DC) “On/Blinking”: Power is being supplied and a link has been Ethernet link LED established to the network.

  • Page 7: Configuration

    ONFIGURATION ETTING TARTED To access the Pro Range Configuration Interface, perform the following steps: 1. Configure the Ethernet adapter on your computer with a static IP address on the 192.168.0.x subnet (for example, IP address: 192.168.0.100 and subnet mask: 255.255.255.0 2.

  • Page 8: Navigation

    AVIGATION The Pro Range Configuration Interface contains four main tabs, each with sub tabs which provide a web-based management page to configure a specific aspect of the SilverNet device: • Status The “Status Tab” displays device status, system logs, and real-time graphs.

  • Page 9: Status

    TATUS The Status tab displays a summary of the link status information, current values of the basic configuration settings (depending on the operating mode), network settings and information, and traffic statistics. AP status page Station status page When using the alignment buzzer, the faster the beeps the better the signal quality. Pro Range User Manual Status...

  • Page 10: Overview

    VERVIEW Wireless This shows you the SSID, operating mode, channel frequency, bitrate, BSSID, encryption mode and the DFS status. Associated Stations Displays the MAC address, SSID and signal information of any stations connected to the AP. System Displays the name of the device, the firmware version and the current system date and time.
  • Page 11 Associated Stations Parameters MAC Address Displays the MAC address of the device. Network States the name of the wireless network. Noise Displays the received noise power at the AP. RSSI Displays the received signal strength. TX Rate shows the transmit bitrate of the device. RX Rate shows the receive bitrate of the device.

  • Page 12: Realtime Graphs

    EALTIME RAPHS There are four different graphs, you can view Load, Traffic, Wireless and connection graphs. Pro Range User Manual Status...

  • Page 13: Admin Tab

    DMIN The Admin tab contains administrative options. This page enables the administrator to configure System Properties, Time Synchronisation, Logging Settings, User Management, Web Administration, SNMP Configuration, LED Configuration, Backup config files / flash new firmware and reboot the device. YSTEM General Settings Local Time Displays the local time according to the time zone.
  • Page 14 Logging System Log Buffer Size Change the size of the log buffer. External System Log Server Input an address that the system log is sent to. External System Log Server Port Input an external server port. Log Output Level Change the type of log report. Cron Log Level Change the level of log report.

  • Page 15: Administration

    DMINISTRATION Use this section to change the administrator password. Router Password Password Enter a new password. Confirmation Re-enter your new password. Pro Range User Manual Admin Tab...

  • Page 16: Snmp

    SNMP Simple Network Management Protocol (SNMP) is a popular protocol for network management. It is used for collecting information from, and configuring, network devices on an IP network. SNMP Information These identifiers are arbitrary and do not affect the server’s function, but they are useful to have.
  • Page 17 SNMP Configuration Enable SNMP Enable SNMP SNMP V2c Read Password Sets the community string for read-only access (to the carriables on the SNMP agent) by the Network Management Station (NMS). The NMS is the software that runs on the SNMP manager. (default: public) SNMP V2c Write Password Sets the community string for read-write access by the SNMP manager.

  • Page 18: Led Configuration

    LED C ONFIGURATION You can configure the LEDs on the device to light up when received signal levels reach the values defined in the four fields. Signal Strength Indicator Interface Choose the wireless interface (wireless network name) to display LEDs for. Signal Strength Indicator LEDs Sets the received signal strength thresholds (in dBm), if the signal is above the threshold, the LED will light up.

  • Page 19: Backup/Flash Firmware

    ACKUP LASH IRMWARE Backup / Restore Download Backup Click to save down the configuration file of the device. Reset to Defaults This will reset the device to the default factory settings (IP address 192.168.1.1) Restore Backup Select the configuration file you wish to upload and click the restore button. Add Functionality Key File: Select the Key file you wish to upload to add extra functionality to the device.

  • Page 20: Reboot

    EBOOT Perform Reboot This option will perform a reboot of your device. Pro Range User Manual Admin Tab...

  • Page 21: Services

    YNAMIC Dynamic DNS (DDNS) allows the device to be reached from the internet via a URL by translating a URL like www.silvernet.com to an IP address like 206.190.36.45 Dynamic DNS Click this link to show information about the current DDNS version.
  • Page 22 Global Settings Allow Non-public IP’s Tick to allow Non-Public IP Addresses. Date Format Input date format code. Status Directory Input device location of status directory. Log Directory Input device location of log directory. Log Length Number of lines stored in log files. Pro Range User Manual Services...
  • Page 23 Add DDNS / Edit DDNS Enabled Tick to enable specified DDNS section. IP Address Version Choose which Internet Protocol version to use for your DDNS. DDNS Service Provider [IPv4] Choose which DDNS service provider to use. Custom Update-URL Input DDNS Update URL from DDNS provider. Custom Update-Script Input custom DDNS update script for updating DDNS provider.
  • Page 24 Advanced Settings IP Address Source [IPv4/6] Defines the source to read systems IPv4-Addresses from, that will be sent to the DDNS provider. Network [IPv4/6] Defines the interface to read systems IP Addresses from. DNS-Server Input non-default DNS Server to detect registered IP Addresses. PROXY-Server Input Proxy server for DDNS detection and updates.
  • Page 25 Timer Settings Check Interval Specify interval to check for changed IP address. Force Interval Specify interval to force updates from DDNS provider. Error Retry Counter Specify number of attempts before DDNS script will stop execution. Error Retry Interval Specify interval in which DDNS script will retry after Error Counter. Pro Range User Manual Services...
  • Page 26 Log File Viewer Read / Reread log file Click to display current system log file. Pro Range User Manual Services...

  • Page 27: Network Tab

    ETWORK The Network tab contains everything needed to set up the networking part of the link. This includes: • Interface: This allows you to configure the IP Address settings, DHCP Server Settings, DNS Settings, Firewall Settings and Physical settings. • Wireless Settings: This allows you to configure settings such as Country Codes, Channel Selection, ACS Scanning, Antenna Gain, Transmit Power, Interface...

  • Page 28: Lan Interface

    LAN I NTERFACE General Setup Protocol Here you can enable DHCP Client or Static (default) DHCP Client If enabled, your device will get an IP address automatically from the network. There must be a DHCP server configured on your network for this to function. Static Allows you to enter a static IP address.
  • Page 29 Use Custom DNS Servers Enter the IP address for the DNS server you wish to use IPv6 Assignment Length (optional) Enter the IPv6 address you wish to give to the device. You will use this IP address to access the device interface. IPv6 Assignment Hint (optional) Enter the gateway IPv6 address of the network the device is connected to.

  • Page 30: Dhcp Server

    DHCP ERVER DHCP Server disabled if ticked, un-tick to enable. DHCP Server The device will act as a DHCP server hand out IP addresses automatically. Start Specifies the lowest leased address to be issued Limit Sets the maximum number of leased addresses Leasetime States the expiry time of leased addresses Dynamic DHCP...
  • Page 31 Advanced Settings Bring up on boot Tick to enable this interface on device boot. Use built in IPv6-Management Tick to enable usage of built in IPv6 management for this interface. Override MAC Address Allows you to specify a different MAC address other than the routers original one.
  • Page 32 Physical Settings Bridge Interfaces Tick to enable bridging of ticked interfaces. Enable STP Enables the Spanning Tree Protocol on this unit. This is disabled by default The Spanning Tree Protocol (STP) is a network protocol. The main purpose of STP is to ensure that you do not create loops when you have redundant paths in your network.
  • Page 33 Firewall Settings Create / Assign Firewall-Zone Choose the firewall zone you want to assign to an interface. Pro Range User Manual Network Tab...

  • Page 34: Wireless Interface

    IRELESS NTERFACE Spectrum scans Click the Scan button to perform a spectrum scan from the AP This will show you a list detailing the channel number, how many other access points are on that channel and the power/interference levels on those channels. Pro Range User Manual Network Tab...
  • Page 35 Click the Scan button to perform a spectrum scan from the Station This will show you a list detailing the channel number, MAC address and encryption method of any devise nearby. You can click the “Join Network” button to connect to a specific AP. From the Wireless Overview page, click the edit button to enter the wireless page Pro Range User Manual Network Tab...

  • Page 36: Device Configuration

    EVICE ONFIGURATION Status This shows the current wireless connectivity of the device, similar to the “Status Tab”. Wireless Network is Enabled Enabled by default, click to disable wireless interface. Country Code Each country has their own power level and frequency regulations. To ensure the device operates under the necessary regulatory compliance rules, you must select the country where your device will be used.
  • Page 37 You can set this depending on the antenna you have, e.g. PICO 12dBi, MICRO 15dBi, LITE 18dBi, MAX 25dBi. When country code is set, the value of the antenna gain will be considered to limit the selectable transmit power, such that the EIRP limits of the country are satisfied.
  • Page 38 5MHz and 10MHz Channel Spectrum Width From the Channel Spectrum Width drop down list, choose 20MHz. A new setting will appear, Channel Bandwidth Used. Select either 20MHz, 10MHz or 5MHz from this new drop down menu. Click Save & Apply to save the configuration. Using higher bandwidth increases throughput.
  • Page 39 Advanced settings Tx Antenna / Rx Antenna Select which spatial streams of the antenna to use. By default, this will be set to Dual Chain. For best results leave on Dual Chain. • 1x1 Chain1 This will force the radio card to operate with 1 spatial stream on the left port of radio card only.

  • Page 40: Interface Configuration

    • Look for CW and WLAN Interference Use this feature to detect and avoid continuous wave (CW) interference and Wireless interference. NTERFACE ONFIGURATION General Setup ESSID If the device is operating in Access Point or Access point WDS mode, specify the wireless network name or SSID (Service Set Identifier) used to identify your WLAN.
  • Page 41 In most cases, we recommend that you use WDS because it enables transparent Layer 2 traffic. The WDS protocol is not defined as a standard, so there may be compatibility issues between equipment from different vendors. Guard Interval This is the space between symbols being transmitted. The Guard Interval is there to eliminate inter-symbol interference.

  • Page 42: Wireless Security

    IRELESS ECURITY All the wireless security settings are set under this section. The operation of the Keys is the same for ALL the Wireless modes. Security The Pro 95 range supports the following wireless security methods: No Encryption If you want an open network without wireless security, select No Encryption. WEP Open System WEP (Wired Equivalent Privacy) is the oldest and least secure security algorithm.
  • Page 43 Note: Operating with WEP security will limit AP to maximum wireless link speed of 54Mbps only. Encryption Select the type of encryption you want to use. Open System (Default) No authentication. We recommend using this option over shared authentication. Shared Key May not be compatible with all Access Points.
  • Page 44 MAC-Filter This setting is only available on the Access Point. MAC-Address Filter Lets you allow only devices with the listed MAC address to associate with this AP, or lets you block devices with the listed MAC address. Mac List Adds the MAC address of the remote device to either block or allow. Advanced Settings 802.11h Tick to enable 802.11h Mode.
  • Page 45 RTS/CTS Threshold This value is set to 2346 as default, which is the maximum 802.11 packet size. We recommend leaving this setting for Point-to-Point links, however, for Multipoint setups we recommend setting the RTS Threshold lower (538). The AP device sends Request to Send (RTS) frames to a receiving station and negotiates the sending of a data frame.

  • Page 46: Vlans

    VLANS The VLANS tab contains everything needed to set up VLANS. Enable VLAN Functionality Check to enable VLANS VLAN Entries VLAN ID Enter the VLAN ID you wish to use Choose to leave off, or Tag or Untag the Ethernet interface Port 1 Choose to leave off, or Tag or Untag the Port 1 interface Port 2...

  • Page 47: Diagnostics

    IAGNOSTICS Use this page to perform some basic network diagnostic tests, such as Ping, Traceroute and Nslookup. Ping Enter an address to Ping, as well as the Internet Protocol Type. Ping is a command-line utility that acts as a test to see if a networked device is reachable. The ping command sends a small amount of data over the network to a specific device and measures the round trip time to receive a response.

  • Page 48: Standards

    SilverNet Limited declares the following: Product Name: PRO Range GEN4 Model No.: PICO, MICRO, LITE, MAX conforms to the following Product Standards: This device complies with the Electromagnetic Compatibility Directive (89/336/EEC) issued by the Commission of the European Community. Compliance with this directive implies conformity to the following European Norms (in brackets are the equivalent international standards.)

  • Page 49: Warnings

    • Consult the dealer or an experienced radio/TV technician for help. Modifications made to the product, unless expressly approved by SilverNet Limited, could void the user’s authority to operate the equipment. RF Exposure Requirements To ensure compliance with FCC RF exposure requirements, the antenna used for this device...
  • Page 50 Hereby, SilverNet Limited declares that this device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

  • Page 51: Troubleshooting

    Use SilverView and run a data test. ARRANTY The PRO Range GEN4 comes with a 2 year warranty as standard. For full terms and conditions of warranty please go to www.silvernet.com/terms-and-conditions/ ONTACT ILVER Email us at support@silvernet.com...

  • Page 52: Other Silvernet Products
