Operation

Features and Controls

Front Panel
1 2
8
9
10 11
Front Panel Button Legend
1 1
2 VOL+/-
3 POWER ( )
4 BAND
5 DISP (Display)
6 USB Port
7 RELEASE ( )
8 2 INTRO (Intro Scan)
9 3 RPT (Repeat Mode select)
10 AS•PS (Automatic Search/Program
Search)
Disc
Information
3 4 5
12 13 14 15 16
11 (Fast Reverse), TUNE/TRACK Down
12 MENU
13 (Fast Forward), TUNE/TRACK Up
14 IR Sensor
15 ST (Stereo/Mono select),
LOC (Local/Distance select)
16 MUTE (turns audio off)
17 A/V Input Connector
18 4 RDM (Random Playback Mode select)
19 5 STOP
20 6
BV7200 User's Manual - page 7
6 7
18
19
20
17
