CISPR Emissions Class A
Classification
Harmonic Emissions Class A
(IEC 61000-3-2)
Voltage Fluctuations Complies
ELECTROMAGNETIC IMMUNITY
This equipment is intended for use in the electromagnetic environment specified below.
The user of this equipment should assure that it is used in such an environment.
IMMUNITY IEC 60601-1-2: (4TH EDITION)
AGAINST
Professional
Healthcare Facility
Environment
Electrostatic Contact discharge: ±8 kV
discharge, ESD Air discharge: ±2 kV, ±4 kV, ±8 kV, ±15 kV
(IEC 61000-4-2)
Electrical fast Power supply lines: ±2 kV
transients / bursts Longer input / output lines: ±1 kV
(IEC 61000-4-5)
Surges on AC mains Common mode: ±2 kV
lines (IEC 61000-4-5) Diferential mode: ±1 kV
3 A/m power 30 A/m
frequency magnetic 50 Hz or 60 Hz
field 50/60 Hz
(IEC 61000-4-8)
Voltage dips and Dip>95%, 0.5 periods
short interruptions Dip 60%, 5 periods
on AC mains input Dip 30%, 25 periods
lines (IEC 61000-4-11) Dip >95%, 5 seconds
ENGLISH
The MaxO2 ME is suitable for use in all
establishments other than domestic and
those directly connected to the public low-
voltage power supply network that supplies
buildings used for domestic purposes.
NOTE: The EMISSIONS characteristics of this
equipment make it suitable for use in industrial
areas and hospitals (CISPR 11 class A). If it is used
in a residential environment (for which CISPR
11 class B is normally required) this equipment
might not offer adequate protection to radio-
frequency communication services. The user
might need to take mitigation measures, such
as relocating or re-orienting the equipment.
ELECTROMAGNETIC
TEST LEVEL ENVIRONMENT
Home
Healthcare
Environment
Floors should be wood,
concrete, or ceramic
tile. If floors are covered
with synthetic material,
the relative humidity
should be kept at levels
to reduce electrostatic
charge to suitable levels.
Mains power quality
should be that of a
typical commercial or
hospital environment.
Equipment which emits
high levels of power
line magnetic fields (in
excess of 30A/m) should
be kept at a distance to
reduce the likelihood of
interference.
If user requires
continued operation
during power mains
interruptions,
ensure that batteries
are installed and
charged. Ensure that
battery life exceeds
longest anticipated
power outages or
provide an additional
uninterruptible
power source.
Recommended separation distances between portable and mobile
RF communications equipment and the equipment
RATED MAXIMUM Separation distance according to frequency
of transmitters in meters
OUTPUT POWER
OF TRANSMITTER
150 kHz to 80 MHz
d=1.2/V1] √P
W
0.01
0.1 0.38
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in meters (m) can be estimated using the equation applicable to
the frequency of the transmitter, where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance
for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propogation
is affected by absorption and reflection from structures, objects, and people.
This equipment is intended for use in the electromagnetic environment
specified below. The customer or the user of this equipment
should assure that it is used in such an environment.
IMMUNITY IEC 60601-1-2: 2014 (4TH
TEST EDITION) TEST LEVEL
Professional
Healthcare
Facility
Environment
Conducted 3V (0.15 - 80
RF coupled MHz)
into lines (IEC 6V (ISM bands)
61000-4-6)
Radiated RF 3 V/m
immunity
(IEC 80 MHz - 2.7 GHz
61000-4-3) 80% @ 1 KHz
AM Modulation
12
80 MHz to 800 MHz
d=1.2/V1] √P
0.12 0.12
0.38
1.2 1.2
3.8 3.8
12 12
ELECTROMAGNETIC ENVIRON-
MENT - GUIDANCE
Home Healthcare
Environment
3V (0.15 - 80 MHz) Portable and mobile RF communications
6V (ISM & equipment (including cables) should
Amateur bands) be used no closer to any part of the
recommended separation distance calculated
from the equation applicable to the
10 V/m
frequency of the transmitter as below.
80 MHz - 2.7 GHz Recommended sparation distance:
80% @ 1 KHz d=1.2 √P
AM Modulation
d=1.2 √P 80 MHz to 800 MHz
d=2.3 √P 800 MHz to 2.7 GHz
Where P is the maximum output
power rating of the transmitter in
watts (W) according to the transmitter
manufacturer and d is the recommended
separation distance in metres (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey a, should be less than the compliance
level in each frequency range b.
Interference may occur in the vicinity of
equipment marked with the following symbol:
WWW.MAXTEC.COM • (800) 748-5355
800MHz to 2.5 GHz
d=2.3 √P
0.23
0.73
2.3
7.3
23
