- Page 1 User’s Manual EXTENDED BATTERY MODULE (EBM) BP240V30ART3UTAA BP240V50ART3UTAA Cyber Power Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www.cyberpowersystems.com K01-0000484-01...
- Page 2 OVERVIEW The CyberPower extended battery modules (BP240V30ART3UTAA / BP240V50ART3UTAA) support 30A/50A polarized plugs, and are designed for variety of Cyber Power UPS systems. When connected to the UPS, the EBM provides extended runtime with a 240VDC external connection. Additional parallel-connected EBM provide the UPS for a longer extended runtime operation.
-
Page 3: Hardware Installation
HARDWARE INSTALLATION Step 3: Rackmount rail Installation HARDWARE INSTALLATION The rails adjust to mount in 19 inch (48 cm) racks from 20.5 These versatile EBM can be mounted in a rackmount or to 36 inches (52 to 91.5 cm) deep. Select the appropriate vertical tower orientation. - Page 4 HARDWARE INSTALLATION Step 4: Adjust rackmount rails to fit your rack How to slide the EBM out from rackmount rails Adjust the rackmount rail depth to match your rack depth. The EBM is secured by a safety locking mechanism midway Attach the rackmount rail to your rack with two screws and of pulling it out of the rack.
-
Page 5: Vertical/Tower Installation
HARDWARE INSTALLATION VERTICAL/TOWER INSTALLATION Adhere four circular rubber pads to the left hand side of ELECTRICAL INSTALLATION the extended battery module. This will become the After completing the hardware installation of the UPS, you bottom side. are now ready to plug in the UPS and connect your equipment. -
Page 6: Basic Operation
Use this input connector to daisy chain the next EBM. Remove the connector cover for access. 6. EBM DC Output Cable BP240V30ART3UTAA / BP240V50ART3UTAA Use this output cable to connect the EBM to a UPS power module or to the next EBM. - Page 7 BASIC OPERATION Connecting UPS to Multiple Extended Battery Modules ○ ○ ○ Connect the 1st EBM to the UPS power module following the “Connecting UPS to Extended Battery Module” instructions. Turn off the DC breaker of the 2nd EBM. Loosen the two screws to remove the battery cable retention bracket of the 1st EBM.
- Page 8 BASIC OPERATION EXTENDED BATTERY MODULES CONFIGURATION Extended Battery Modules can be configured by the user to display correct estimated battery runtimes. Press the “ENTER” button to activate the “MAIN MENU”. Press the “▲” and “▼” buttons to scroll to the “Configure” menu. Press the “ENTER”...
-
Page 9: Maintenance
MAINTENANCE CAUTION! To avoid electric shock, turn off and unplug the EBM from Storage the wall receptacle (if installed) before servicing the battery. To store your extended battery modules for a long period of time, turn the CAUTION! Only use tools with insulated handles. Do not lay tools or DC breaker off, cover it and store with the batteries fully charged. -
Page 10: Technical Specifications
3. You must provide a dated Proof-of-Purchase receipt (or other proof of the original purchase) and provide a description of the defect. 4. Pack and ship the product to CyberPower and, if requested, the item(s) of Connected Equipment, a repair cost estimate for the damage to the Connected Equipment, and all claim forms that CyberPower provides to you. -
Page 11: Product Registration
If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required). - Page 12 (collectively, "High Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums.
-
Page 13: Conformance Approvals
Cet appareil numerique de la class A respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada. This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for omissions or errors.
