AML-3
Multi
1)
Connect instrument to computer serial port using
the provided underwater cable. Default BAUD is
9600.
2)
Apply 8-30 VDC to flying leads
3)
Instrument will boot in ~10 seconds. Data will begin
to stream automatically
4)
Send carriage return to halt data stream
5)
Send 'monitor' command to stream data
6)
Send
'help'
command to list all available commands
Refer to AML-3 RT User Manual for a complete list of commands
and configurations.
RT
Quick Start Guide
Stream Serial Data
The MCBH provides a serial connection for data
streaming and configuration via command line
1
6
2
MCBH-6 Face View
5
3
4
8-30 VDC
Advertisement
Table of Contents
Related Manuals for AML AML-3 RT
Summary of Contents for AML AML-3 RT
- Page 1 Send carriage return to halt data stream MCBH-6 Face View Send ‘monitor’ command to stream data Send ‘help’ command to list all available commands Refer to AML-3 RT User Manual for a complete list of commands and configurations.
- Page 2 AML-3 Quick Start Guide Connect via Sailfish Sailfish provides a user-friendly means of streaming data, configuring an instrument, and updating firmware Install Sailfish on a Windows PC from either: Sailfish will detect the instrument and a tile will ● AMLoceanographic.com appear ●...
