Green Brook Aquila SLLLED3 Installation Instructions

Part Nos: Cool White - SLLLED3, SLLLED4, SLLLED7, SLLLED14,
Part Nos: Warm White - SLLLED3WW, SLLLED4WW,
SLLLED7WW, SLLLED14WW, SLLLED18WW
This product should be installed by a competent person
and in accordance with the current IET Wiring Regulations.
If in doubt,consult a qualified electrician.

IMPORTANT

• Never look directly into the LED light source.
• Do not place in water or other liquids
• Never operate with wet hands
• Never cover the fitting
• Never operate when the casing is open, or when the
wiring casing is missing or damaged, or when the diffuser
is defective
• Never attempt to repair this unit yourself, there are no user
serviceable parts
• Never remove the diffuser
1. Fixing holes must be clear of any obstruction (eg.cables)
between the mounting surface and fitting. The minimum
distance between the fitting and any adjacent
flammable surface is 10mm (as shown In Dia.1).
2. Select the type of brackets you need to use and mark off
the fixing points. If fixing to a shelf or under a cupboard
check the screw size required and screw into place.
(see Dia.2).
Installation Instructions
for Aquila Range - LED Link Lights
SLLLED18 & SLLLED22
& SLLLED22WW
IMPORTANT

GENERAL INFORMATION

INSTALLATION

Dia.1
Dia.2
Dia.3
